Side 1/30

Rev. 1.0

64GB Extended Capacity Secure Digital Card

Transcend Information Inc.

Description

Transcend secured digital extended capacity Card

series are specifically designed to meet the High

Capacity, High Definition Audio and Full HD Video

requirement for the latest Digital Cameras, DV

Recorders, Mobile, etc,. The new defined Speed

Class enables the host to support AV applications to

perform real time recording to the SD memory card.

Placement

Front Back

Features

•

ROHS compliant product.

•

Card Lid material: PC + ABS

•

Operating Voltage: 2.7 ~ 3.6V

•

Operating Temperature: -25 ~ 85°C

•

Durability: 10,000 insertion/removal cycles

•

Compatible with SD Specification Ver. 3.0

•

Mechanical Write Protection Switch

•

Supports Speed Class 10 Specification

•

Supports Copy Protection for Recorded Media (CPRM)

for SD-Audio

•

Support exFAT file system

•

Form Factor: 24mm x 32mm x 2.1mm

Pin Definition

SD Mode SPI Mode

Pin No.

Name

Type

Description Name

Type

Description

CD/DAT

I/O/PP

Card Detect/Data Line [Bit3]

CS I

Chip Select (neg true)

CMD PP Command/Response

DI I

Data In

SS1

S Supply voltage ground

VSS S

Supply voltage ground

S Supply voltage

VDD S

Supply voltage

CLK I Clock

SCLK

Clock

SS2

S Supply voltage ground

VSS2

Supply voltage ground

DAT0

I/O/PP

Data Line [Bit0]

DO O/PP

Data Out

DAT1

I/O/PP

Data Line [Bit1]

RSV

DAT2

I/O/PP

Data Line [Bit2] RSV

Produkspesifikasjoner

Merke:	Transcend
Kategori:	minnekort
Modell:	SDXC
Vekt:	2 g
Bredde:	24 mm
Dybde:	32 mm
Høyde:	2.1 mm
Varighet:	10000 sykluser per logiske sektor
Sertifisering:	CE/FCC
Antall per pakke:	1 stykker
Kapasitet:	64 GB
Produktfarge:	Sort
Internminnetype:	NAND
Driftstemperatur (T-T):	-25 - 85 °C
Harmonisert system (HS)-kode:	85235190
Krav til strømforsyning:	2.7 - 3.6V
Plugg inn og spill:	Ja
Type flashkort:	SDXC
Lesehastighet, medier:	30 MB/s
Flash-minneklasse:	Klasse 10
