Side 1/20

Table of Contents

1. Important Safety Instructions 2

2. Overview 2

3. Feature Identiﬁcation 3

4. Setup 4

4.1 Power Requirements 4

4.2 Adjusting Storage Shelf Dividers 4

4.3 Connecting Devices and 4

Powering the AC Unit

4.4 Door Locks 5

5. Wall Mounting 5

6. Desktop/Floor Placement 5

7. Speciﬁcations 6

8. Storage, Service and Cleaning 6

9. Optional Casters and Handle 6

10. Warranty and Product Registration 7

Español 8

Français 14

AC Charging Station

16-Outlet Models: CSC16AC (CSC16ACW)

Owner’s Manual

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

1. Important Safety Instructions

2. Overview

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that must be followed during the installation and operation of the product described in this manual.

Failure to comply may invalidate the warranty and cause property damage or personal injury.

AC Unit:

• To remove the AC unit from the supply mains, the power cord serves as a disconnect device.

• If any of the following situations arise, schedule an appointment to have your equipment inspected by a service technician:

• The equipment has been exposed to moisture

• The equipment has been dropped and damaged

• The equipment shows obvious signs of breakage

• The equipment is not functioning properly or is not functioning according to the instructions described in this Owner’s Manual

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support

equipment or to significantly affect its safety or effectiveness is not recommended.

Charging Station Cabinet:

• Keep the charging station in a controlled indoor environment away from moisture, temperature extremes, flammable liquids and gasses, conductive

contaminants, dust and direct sunlight.

• Leave adequate space around the charging station for proper ventilation. Do not block, cover or insert objects into the charging station’s external

ventilation openings.

• The charging station is extremely heavy. Use caution when handling the charging station. Do not attempt to unpack or mount it unassisted. Use a

mechanical device such as a forklift or pallet jack to move the charging station in the shipping container.

• Do not place any object on the charging station, especially containers of liquid, and do not stack items on the cabinet.

• Inspect the shipping container and the charging station for shipping damage. Do not use the charging station if it is damaged.

• Use caution when cutting packing materials. The charging station could be scratched, causing damage not covered by the warranty.

• Save all packing materials for later use. Repacking and shipping the charging station cabinet or equipment without the original packing materials

may cause product damage that will void the warranty.

For Wall-Mount and Desktop Installations:

• Before mounting, first make sure that the wall or desk surface can safely support the combined load of the charging station, equipment stored and

all attached hardware and components.

• Always use suitable mounting means when installing to cinder block, concrete, drywall or wood studs.

• For desktop installations, the mounting brackets that shipped with the unit can also be used to secure the charging station to a desktop surface.

Your charging station is an all-in-one solution for storing and charging up to 16 devices. Your charging station can be conveniently mounted to walls, as

well as used for stationary desktop or floor placement installations. To prevent theft and device tampering, your charging station enclosure comes

equipped with locking steel doors.

3. Feature Identification

CSC16AC(W)

Locking Split Doors

Adjustable Storage Shelves (Holds up to 16 Devices)

Blanking Panel (Removable)

Power Cord Access Holes (1 Located on Each Side)

Padlock Hasp (User Supplies Lock)

Cable Lock Routing Holes (User Supplies Lock)

Rear Panel with Keyhole Wall Mount Slots (See Section 5 for More Information)

Not Shown:

AC Charger Unit (Preinstalled)

Keys

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Bærbar datamaskin
Modell:	CSC16AC
Vekt:	34090 g
Bredde:	769.6 mm
Dybde:	513 mm
Høyde:	477.5 mm
Bruksanvisning:	Ja
Plassering:	Vegg
Opprinnelsesland:	China
Pakkevekt:	46490 g
AC-inngangsspenning:	120 V
AC-inngangsfrekvens:	50 - 60 Hz
Maksimal skjermstørrelse:	15 "
Støttede bærbare enheter:	Laptop
Kabellengde:	3.05 m
Produktfarge:	Sort
Pakkedybde:	599.4 mm
Pakkehøyde:	622.3 mm
Pakkebredde:	855.9 mm
Bærekraftsertifikater:	RoHS
Modell/Type:	Veggmontert
Kroppsmateriale:	Stål
Lås-type:	Nøkkel
Strøm:	12 A
Masterkassens (ytterkassens) bruttovekt:	46270 g
Masterkassens (ytterkassens) lengde:	855 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	599.9 mm
Masterkassens (ytterkassens) høyde:	623.1 mm
Antall:	1
Låser:	Ja
Antall støttede enheter:	16
Utstyrsstikk som støttes:	AC
