NetDirector
®
KVM Switches
Purchased product
may differ from image.
Models:
B064-016-02-IPH
B064-016-04-IPH
B064-032-01-IPH
B064-032-02-IPH
B064-032-04-IPH
Cat5 IP
2
Table of Contents
Table of Contents ..................................2
Introduction ......................................3
Important Safety Notice..................................3
Features ...............................................3
Remote Console Computer Requirements .................4
Connected Computer/Server Requirements ................4
Server Interface Units (SIUs) ..............................4
Supported Operating Systems ............................4
Supported Browsers ....................................5
Components ...........................................5
Hardware Setup ...................................7
General Safety Instructions...............................7
Stacking................................................8
Rack Mounting..........................................8
Single-Stage Installation..................................8
Two-Stage Installation ...................................9
Laptop USB Console (LUC) ............................. 10
Hot Plugging.......................................... 10
Powering O & Restarting .............................. 10
Port ID Numbering .................................... 10
Super Administrator Setup.........................11
First Time Setup....................................... 11
Network Setup - IP Address Determination ............... 11
Changing the Super Administrator Login ................. 13
Logging Into the B064-Series KVM Switch ............13
Local Console Login ................................... 13
Browser Login ........................................ 14
AP Windows Client Login ............................... 14
AP Java Client Login.................................... 15
OSD Operation ...................................16
The OSD Main Page ................................... 16
OSD Tab Bar.......................................... 17
Port Access........................................... 17
User Settings ......................................... 18
(B064-008-01-IPG and B064-016-01-IPG Models only)
Connections.......................................... 19
History............................................... 23
Favorites ............................................. 24
User Preferences ..................................... 25
Sessions ............................................. 26
Access ............................................... 26
Port Conguration .................................... 27
Blade Conguration ................................... 29
User Management .................................... 30
Device Management................................... 36
Device Information .................................... 36
Operating Mode ...................................... 37
Network ............................................. 37
Advanced Network Management Settings ................ 39
OOBC ............................................... 48
Security .............................................. 50
Date/Time............................................ 54
Blade Server Conguration ............................. 54
Log .................................................. 56
Maintenance ......................................... 57
Download ............................................ 60
Remote Session...................................61
Control Panel ......................................... 61
The OSD Toolbar...................................... 73
Multiuser Operation ................................... 75
Auto Scanning ........................................ 75
The Log Server....................................76
Installation ........................................... 76
Starting Up ........................................... 76
The Menu Bar ........................................ 76
Congure ............................................ 77
Events ............................................... 78
Options .............................................. 79
Help ................................................. 79
The Log Server Main Screen - Overview .................. 79
Appendix ........................................81
Keyboard Emulation .................................. 81
General Operation Troubleshooting ..................... 82
Administration Troubleshooting......................... 83
Mouse Troubleshooting................................ 83
Virtual Media Troubleshooting .......................... 83
AP Windows Client Troubleshooting ..................... 84
WinClient ActiveX Viewer Troubleshooting................ 84
Panel Array Mode Troubleshooting...................... 85
Java Applet & AP Java Client Troubleshooting ............. 85
Log Server Troubleshooting ............................ 85
Sun Systems Troubleshooting .......................... 86
Specications ....................................87
Factory Default Settings................................ 87
Serial Adapter Pin Assignments ......................... 87
Fan Location & Speed Information ...................... 88
Temperature Sensor Location .......................... 88
Warranty ........................................89
3
Introduction
Features
Important Safety Notice
BATTERY SAFETY NOTICE
There is a risk of explosion if the battery is replaced with an incorrect type. Dispose of used batteries
according to the relevant instructions.
BATTERIE AVIS DE SÉCURITÉ
II existe un risque d’explosion si la batterie est remplacée par un incorrect tapez. Jeter les piles usaes
selon la pertinente instructions.
Directly connect up to 16 (B064-016-01-IPH, B064-016-02-
IPH, B064-016-04-IPH) or 32 (B064-032-01-IPH, B064-032-
02-IPH, B064-032-04-IPH) computers/servers
Accomodate additional computers/servers in a two-level
cascade installation
Two 10/100/1000 Mbps network connections for redundant
LAN or two IP operation
Supports both IPv4 and IPv6
Blade server support
• Supports 1 (B064-032-01-IPH), 2 (B064-016-02-IPH, B064-
032-02-IPH) or 4 (B064-016-04-IPH, B064-032-04-IPH)
remote sessions
• 1 Local and 1 Remote User can simultaneously access the
B064-032-01-IPH
• 1 Local and 2 Remote Users can simultaneously access the
B064-032-02-IPH or B064-016-02-IPH
• Local and Remote Users can share 4 sessions by accessing
the B064-016-04-IPH or B064-032-04-IPH
Up to 32 users can remotely share one user port
Create up to 64 user accounts
Multi-level authentication: super administrator;
administrator; user
Advanced security features include password protection
and advanced encryption technologies - TLS 1.2 Encryption;
2048 bit RSA (encryption key up to 4096 bit)
RJ45 connectors and Cat5e cable allow for a more ecient
installation
Browser access can be disabled – Windows
®
and Java GUI
AP programs provided for non-browser connectivity
Supports web-friendly access with Web Client Viewer -
users can remotely access all connected servers and PCs
directly o web-browsers without Java or browser plug-in
installation
Graphical OSD and toolbars provide convenient, user-
friendly operation
Full-screen graphical OSD for the local console
Full-screen or sizable remote desktop window; in full-screen
mode the remote desktop display scales to user’s monitor
display size
Panel Array Mode displays up to 32 ports at the same time
High video resolution: up to 1920 x 1200 @ 60Hz – 24 bit
color depth for the local console; up to 1920 x 1200 @ 60Hz
with 24 bit color depth for remote sessions at up to 164 ft.
(50 m)
Features advanced FPGA graphics processor for improved
video quality
Multi-language support; OSD can be displayed in English,
Spanish, French, German, Russian, Italian, Japanese, Korean,
traditional Chinese and simplied Chinese
Software (on-screen) keyboard
UltraSync for USB mice – local and remote mouse
movement are the same – no need to constantly re-sync
the two movements
Windows-based Log Server
Support all major server platforms and VT100-based serial
devices
Support multi-platform server environments: PS/2 and USB
Support 10Base-T, 100Base-T, 1000Base-T, Auto-Sense, TCP/
IP, HTTP, DNS, DHCP, UDP, ARP, Ping
Remote authentication support: RADIUS, LDAP, LDAPS, and
Active Directory
Flash upgradeable rmware over the network
Server Interface Unit (SIU) information is stored by the KVM
switch. When switched to a dierent port, the port settings
(Port OS, OS Language, etc.) for the SIU are transferred
along with it
Virtual Media allows computers connected to the KVM
switch by a B055-001-USB-V2 SIU to access DVD/CD drives,
ash drives and other storage media as if they were directly
connected to the computer (works in either the operating
system or BIOS level)
Includes three USB ports on the front of the unit that can
be used for an external keyboard and mouse or for virtual
media functionality
Dual power supplies allow the unit to continue running in
the event one power supply ceases to receive power. If one
power supply fails, the other powers supply takes over to
keep the unit powered and functional.
Temperature sensors determine if fans are needed to cool
the device and at what speed. The fan speed increases/
decreases along with the temperature, using energy more
eciently and increasing the life of the fans and switch.
Track critical events on the installation via SMTP email
notication, SNMP traps, the included Windows-based Log
Server or Syslog server
Users can choose between any combination of 56-bit DES,
168-bit 3DES, 256-bit AES, 128-bit RC4 or Random for
independent Keyboard/Mouse, video and virtual media data
encryption
Support Exit Macros
BIOS level access
• Supports Link Local IPv6 Address and IPv6 Stateless
Autoconguration protocols
Modem out of band Dial In, Dial Out, Dial Back support
Automated Certicate Signing Request (CSR) creation utility
Supports importing third party CA certicates
Supports FIPS 140-2 level 1 security standards
Local monitor’s EDID information stored in connected
Server Interface Units (SIUs) for optimal display resolution
