Side 1/8

Owner’s Manual

4-Port RS-232

Serial PCIe Card

with Breakout Cable

Model: PCE-D9-04-CBL

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

16-02-245-93354D-EN.indd 1 2/24/2016 10:39:10 AM

Product Features

• Adds four DB9 RS-232 Serial ports to your

computer or server

• Single-chip design provides optimum reliability and

speed, reducing CPU load from conventional bridge-

chip cards

• Supports data transfer rates up to 250 Kbps on

each port

• Single-Lane (x1) PCI-Express with throughput up to

2.5 Gbps

• PCI Express 1-Lane (x1) interface, which is also

compatible with x4, x8 and x16 PCIe slots

• Compliant with PCI-Express Base Speciﬁcation

Revision 1.1

• Compatible with industrial standard

16450/16550 UART

• On-chip 256-byte depth FIFO in Transmit &

Receive paths of each port

• Supports hardware and software ﬂow control

• 5-, 6-, 7- and 8-bit serial formats supported

• Supports Even, Odd, None, Space and Mark parity

• Supports 1 or 2 Stop bit operation

• Supports Re-map function for legacy ports

• Standard size bracket

16-02-245-93354D-EN.indd 2 2/24/2016 10:39:10 AM

Optional Accessories

System Requirements

Package Includes

• P520-006 DB9 Serial Extension Cable – 6 ft.

• Computer with an available PCI Express (PCIe)

expansion slot (x1, x4, x8, x16)

• Compatible with Windows

(2000 and later)

and Linux

(2.6.13 and later)

• PCE-D9-04-CBL RS-232 Serial PCI Card

• DB9 Breakout Cable

• Driver CD

• Owner’s Manual

16-02-245-93354D-EN.indd 3 2/24/2016 10:39:10 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	PCI-kort
Modell:	PCE-D9-04-CBL
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	360 g
Vertsgrensesnitt:	PCIe
Utvidelseskort standard:	PCI 1.1
Produktfarge:	Black, Green
Pakkedybde:	170.2 mm
Pakkehøyde:	55.9 mm
Pakkebredde:	137.2 mm
Seriell grensesnittype:	RS-232
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	8471.80.1000
Støttede Windows operativsystemer:	Ja
Drivere medfølger:	Ja
Intern:	Ja
Støttede Linux operativsystemer:	Ja
Utvidelseskort formfaktor:	Full høyde/lav profil
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332193633
Masterkassens (ytterkassens) bruttovekt:	4040 g
Masterkassens (ytterkassens) lengde:	355.6 mm
Produkter per masterkasse (ytterkasse):	10 stykker
Masterkassens (ytterkassens) bredde:	315 mm
Masterkassens (ytterkassens) høyde:	160 mm
Enkel installering:	Ja
Dataoverføringsfrekvens (maks.):	2.5 Gbit/s
Baud-hastighet:	250 Kbit/s
