Side 1/12

Owner’s Manual

SmartRack

Wiring Closet Exhaust Fan

Model: SRCLOSETFAN

(Series number: AG-0047)

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 5 • Français 9

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

19-10-070-9339A9.indb 1 12/5/2019 2:42:08 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that must be followed during the installation and operation

of the product described in this manual. Read all instructions and warnings thoroughly before attempting

installation. Failure to comply may affect the warranty and cause property damage and personal injury.

Connection, Installation and Location Warnings

WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

• Inspect the shipping container and the unit for shipping damage. Do not use the unit if it is damaged.

• Install in a controlled indoor environment, away from moisture, temperature extremes, conductive contaminants, dust and direct sunlight.

Do not expose to water or rain. FOR USE IN CONTROLLED IT ROOM APPLICATIONS ONLY.

• For best performance, keep the indoor temperature between 32° F and 104° F (0° C and 40° C).

• Installation is to be performed by a SKILLED PERSON, knowledgeable in installing fans.

• All Installation work and electrical wiring must be done by SKILLED PERSON(s) in accordance with all applicable codes and standards,

including ﬁre-related construction.

• Install in accordance with local and national electric codes ANSI/NFPA 70 and Canadian Electrical Code, Part I, C22.1.

• To reduce the risk of ﬁre, connect only to a circuit provided with 20A branch circuit overcurrent protection in accordance with the National

Electrical Code, ANSI/NFPA 70 and the Canadian Electrical Code, Part I, C22.1.

• Not intended for ceiling mounting. Do not mount in a ceiling. DO NOT MOUNT IN A FIRE-RATED WALL. Not for use in kitchens. Do not

operate without air ﬁlter installed. Always install the outer covers with the supplied screws.

• Do not attempt to modify or drill holes into the enclosure for mounting. Use the mounting holes provided.

• It is the installer’s responsibility to choose appropriate hardware to mount the fan.

• When cutting or drilling into wall, do not damage electrical wiring and other hidden utilities.

• When using tools, use eye protection and follow all other safety precautions recommended by the tool Manufacturer and required by

applicable regulations.

• Set up a schedule and change the fan ﬁlter regularly. Keep hair, clothing and loose objects away from the fan intakes. There is a risk of

property damage and personal injury. After ﬁlter replacement, be sure to fasten the cover with the screws. The fan does not require routine

maintenance. Do not open the fan for any reason. There are no user-serviceable parts inside.

• Do not obstruct the fan openings. Do not block, cover or insert objects into the openings of the fan.

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause failure of the life

support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended.

Explanation of Symbols

Caution, Risk of Danger

Caution, Moving Fan Blades

Caution, Electric Shock Hazard

19-10-070-9339A9.indb 2 12/5/2019 2:42:09 PM

Mounting

Notes:

• This product should only be installed by someone of good mechanical ability, with basic building experience and a full understanding of this instruction

manual.

• Installers are responsible for providing appropriate installation hardware for the mounting surface.

• Make sure that the mounting surface can safely support the combined load of the equipment and all attached hardware and components.

5 6

If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs.

The use of a stud ﬁnder is highly recommended.

These instructions show an installation in which the fans draw in cool air from the outside. For installations in which

the fans pull warm air out from the inside, install the bracket on the inside of the wall and the fan on the outside of

the wall.

If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs.

The use of a stud ﬁnder is highly recommended.

INSIDE

INSIDE INSIDE

OUTSIDE

19-10-070-9339A9.indb 3 12/5/2019 2:42:12 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	husholdningsvifte
Modell:	SmartRack SRCLOSETFAN
Innebygd skjerm:	Nei
Vekt:	9800 g
Bredde:	327 mm
Dybde:	438.2 mm
Høyde:	177.8 mm
Støynivå:	65 dB
Bruksanvisning:	Ja
Opprinnelsesland:	China
Pakkevekt:	13240 g
Inngangsspenning:	110 - 120 V
Inngangseffekt:	- W
Maksimal luftstrøm:	475 cfm
Antall strømkabler:	1
Pakkedybde:	525.8 mm
Pakkehøyde:	261.6 mm
Pakkebredde:	421.6 mm
Inngangsfrekvens:	50/60 Hz
Dekselfarge:	Sort
Antall vifter:	2 vifter
Nedkjølingskapasitet i watt (maks.):	- W
