Side 1/8

SmartRack

Assembly Instructions

Models:

SRCOLOKIT42U, SRCOLOKIT48U

1111 West 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Parts List

Colo Door Hinge

Brackets

Divider

Plate

Roof Cable

Channel

Blocking

Plate

Divider Plate

Bracket

M6 Screw M6 Flat Head

Screw

Lock Washer 8-32 Screw Cable Channel

Plate

Label

A B C D E F

G H I J K L M

x4x4 x2

x4 x17 x17x8 x8 x1x2

x1x1 x1

Required tools (User Supplied):

Phillips Head Screwdriver

WARNING: The rack enclosure is extremely heavy. Do not attempt to unpack, move, assemble or install the

enclosure without assistance. Until it has been properly assembled and stabilized, the enclosure is prone to

tipping and could cause property damage and/or personal injury. Use extreme caution when assembling

the enclosure. Do not attempt to install equipment without ﬁrst stabilizing the enclosure.

MODEL:

SRCOLOKIT42U

WWW.TRIPPLITE.COM

SERIAL NUMBER

XXXXXXXXXXXXXXXX

step

Remove front and

rear doors.

For front doors, attach additional

hinge brackets to door frame

on the same side as the existing

hinge brackets.

For rear doors, move two hinge

brackets so that all brackets

are on the same side of the

door frame.

2 4

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	dataeske
Modell:	SRCOLOKIT42U
Opprinnelsesland:	China
Pakkevekt:	50090 g
Produktfarge:	Sort
Pakkedybde:	1054.1 mm
Pakkehøyde:	749.3 mm
Pakkebredde:	355.6 mm
Harmonisert system (HS)-kode:	7326.90.8688
Rack-kapasitet:	42U
Masterkassens (ytterkassens) bruttovekt:	50090 g
Masterkassens (ytterkassens) lengde:	1054.1 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	355.6 mm
Masterkassens (ytterkassens) høyde:	749.3 mm
