Owner’s Manual

Multi-Function Cable

Tester with Wire Tracker

(RJ45, RJ11, BNC, USB)

Model: T010-001-K

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

www.tripplite.com/warranty

19-04-414-9334DF-EN.indd 1 6/21/2019 8:26:41 AM

Package Includes

Product Features

• Main Tester Unit

• Remote Tester Unit

• Remote Probe Unit

• RJ11 Jumper Cable – 6 in.

• RJ45 Jumper Cable – 6 in.

• RJ11 to Alligator Clips Adapter

• Headphones for Cable Tracing

• Owner’s Manual

• All-in-one, multi-function kit for testing cable wiring, length, fault, and

location of cables

• Easy-to-use LCD interface

• Test cable wiring for open, short, cross, reverse and pairing connection

• Determine location of open circuit position

• Determine the length of a cable, whether in a wall or on a spool—

up to 4,920 ft. (1,500 m)

• Perform cable tracing to ﬁnd a cable within a bundle of cables

• Allows for testing of RJ45 (STP/UTP), RJ11, USB and BNC cabling and

common metal wires (using alligator clips adapter)

19-04-414-9334DF-EN.indd 2 6/21/2019 8:26:41 AM

Main Tester Unit

RJ11 Port

USB-B Port

BNC Port

RJ45 SCAN Port – Used for cable tracing test.

RJ45 MAIN Port – Used in cable wiring, length and fault test.

UP Button – Press to move up through the menu in the LCD interface.

DOWN Button – Press to move down through the menu in the LCD

interface.

ON/OFF Button – Press to turn the Main Tester on and off.

ENTER Button – Press to select an option in the LCD interface menu.

6 8

7 9

345
