Tripp Lite WorkWise WWBASE-WH Bruksanvisning

Tripp Lite Kant WorkWise WWBASE-WH

Les nedenfor 📖 manual på norsk for Tripp Lite WorkWise WWBASE-WH (24 sider) i kategorien Kant. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/24

Owner’s Manual

Sit-Stand Electric

Adjustable Desk

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Important Safety Instructions 2

Parts List 3

Tools Required 3

Assembly 4

Handset Panel 8

Operation 8

Resetting the Handset 8

Adjusting Desk Height 8

Creating Height Presets 9

Adjusting the LED Display Height 9

Setting the Upper and Lower Limits 9

Troubleshooting 10

Speciﬁcations 10

Warranty and Product Registration 11

Español / Français 12

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation, operation, and storage of this

product. Failure to heed these instructions and warnings may affect the product warranty.

• Do not sit or stand on the desk frame, and do not crawl or lie under the desk frame.

• Do not place any objects taller than 20 inches underneath the desk.

• Make sure no obstacles are in the desk’s path, the desk top is not touching any walls and all cords are appropriate length to

accommodate the change in height.

• Keep children away from electric height-adjustable desks, control units and handsets. There is a risk of injury and electric shock.

• This height adjustable desk has electric motors and is designed for use in dry work areas only. Keep all electrical components away from

liquids.

• Do not open any of the components (e.g. Legs, Control Box, or Switch); there is a danger of electric shock.

• This product is designed with a duty cycle of 10% (2 minutes on, 18 minutes off).

• In the event of a power outage or if the power cord is unplugged, a manual reset may be necessary (see Operation section for more

information).

• The desk height is adjustable so that it can be positioned at the most ergonomically suitable height. Any other use beyond the parameters

of proper use or handling as set by the manufacturer is at the user’s risk.

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the

life support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended.

Parts List

Tools Required

Part Qty.

Leg 2

Foot 2

Frame End (Control Box) 1

Frame End 1

Center Rails 2

Side Bracket 2

Control Box 1

4 mm Hex Key (Included) Phillips Head Screwdriver

and/or Power Drill

Tape Measure

Part Qty.

Handset 1

Power Cord 1

Male to Female 1

Extension Cable (4.3 ft.)

Part Qty.

M6 x 10 Screw 16

M6 x 14 Screw 12

M5 x 20 Wood Screw 7

M5 x 16 Wood Screw 2

(Used to Attach Handset)

Cable Clip 10

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	Kant
Modell:	WorkWise WWBASE-WH
Vekt:	24950 g
Dybde:	575.1 mm
Pakkevekt:	30390 g
Sertifisering:	ROHS, UL 1004-7, UL 1004-1, UL 508:1999, CSA C22.2 100-04, CSA C22.2 77-95, CSA C22.2 14-10
Materiale:	Stål
Antall per pakke:	1 stykker
Produktfarge:	Hvit
Pakkedybde:	264.2 mm
Pakkehøyde:	233.7 mm
Pakkebredde:	1054 mm
Modell/Type:	AV-grunnsokkel
Maksimalvekt (kapasitet):	165 kg
