Side 1/13

TB521-2122-01

User Guide

Xbox 360

game console with one of the following Xbox

cables to support digital audio output:

• Component A/V cable

• VGA A/V cable

• S-Video A/V cable

• Advanced SCART A/V cable

• HDMI audio adapter cable

• Composite A/V cable with digital output

Available USB port

What’s in the Box

DSS2 Surround Sound Processor

Digital Optical Cable Turtle Beach Sticker

watch DXL1 training videos at:

www.youtube.com/TurtleBeachVideos

Overview pg 1

Using the Amplier pg 2

DSS2 Overview pg 3

Setup

Xbox 360

pg 5

Home Theater

pg 7

Connecting a Digital Music Player pg 8

Dolby

Digital Surround Sound pg 9

Surround Sound Angles pg 10

Equalizer Presets pg 12

Troubleshooting pg 12

Technical Speciﬁcations pg 13

Important Safety Information pg 13

Table of Contents

System Requirements

USB Cable Xbox 360

Talkback Cable

DXL1 Headset with In-line Amplier

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

1 2

Overview

Chat Volume

Adjusts the volume of incoming chat from other players.

Game Volume

Adjusts the game sound volume.

Xbox 360 Talkback Cable Jack

Connect the included Xbox 360 Talkback Cable from this jack

to the Xbox 360 controller. (see pg. 6 for details)

Mic Mute Switch

Switch to MUTE to mute the microphone. The LED will turn

red when the mic is muted and green when the mic is on.

Mic Mute

Switch

Xbox 360

Talkback Cable

Jack

Game

Volume

Chat

Volume

Using the Ampliﬁer

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

The DXL1 delivers the Dolby surround sound advantage, combining the DXL1 headset with the DSS2 surround sound processor

that transforms any stereo headset into a full Dolby

Digital surround sound. The result is an amazing recreation of the 3D

sound cues in the game, which sounds as if you’re listening to real surround sound speakers placed all around you. Dolby

Digital surround sound lets you pinpoint the position of sound cues to hear exactly where everything is coming from, so you’ll

enjoy a more realistic and immersive gaming experience.

The DXL1 headset features massive 50mm speakers and lightweight design for amazing sound quality and extreme comfort.

With the DXL1, you’ll be able to hear sound cues that are missed with conventional TV speakers, such as the sound of enemy

footsteps or the click of a loading weapon in the distance. That means you’ll react faster and take them out before they can

take you out, giving you the edge that can make the difference between winning and losing.

Mic Mute

LED

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

GAME

CHAT

ON MIC MUTE

Produkspesifikasjoner

Merke:	Turtle Beach
Kategori:	hodetelefon
Modell:	Ear Force DXL1
Produkttype:	Hodesett
Vekt:	181 g
Tilkobling:	2.5mm, USB, 3.5mm
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Volumkontroll:	Rotasjon
Anbefalt bruk:	Spilling
Impedans:	- Ω
USB-tilkobling:	Ja
Mikrofonfrekvens:	50 - 15000 Hz
Kabellengde:	4.87 m
Kabler inkludert:	USB
Hurtigstartsguide:	Ja
Støttede Windows operativsystemer:	Ja
Bæremåte:	Hodebånd
Hodetelefonsfrekvens:	20 - 20000 Hz
Hodetelefonssensitivitet/hodetelefonsfølsomhet:	120 dB
Driverenhet:	50 mm
Mikrofondemping:	Ja
Hodesett-type:	Stereofonisk
Øresammenkobling:	Circumaural
Magnettype:	Neodym
