Side 1/15

TB521-2258-01

User Guide

Xbox 360

game console with one of the following Xbox

cables to support digital audio output:

• Component A/V cable

• VGA A/V cable

• S-Video A/V cable

• Advanced SCART A/V cable

• HDMI audio adapter cable

• Composite A/V cable with digital output

PC/laptop or Mac

with either on-board or external sound card with digital optical output and Dolby Digital Live installed.

Available USB port

What’s in the Box

DSS2 Surround Sound Processor

Digital Optical Cable Turtle Beach Sticker

watch DX12 training videos at:

www.youtube.com/TurtleBeachVideos

Overview pg 1

Using the Amplier pg 2

DSS2 Overview pg 3

Setup

Xbox 360

pg 5

Home Theater

pg 7

PC/Mac

pg 8

Connecting a Digital Music Player pg 9

Dolby

Digital Surround Sound pg 10

Surround Sound Angles pg 11

Equalizer Presets pg 12

Troubleshooting pg 13

Technical Speciﬁcations pg 14

Important Safety Information pg 14

Table of Contents

System Requirements

USB Cable Xbox 360

Talkback Cable

Ear Force X12 Headset with In-line Amplier

1 2

Overview

Chat Volume

Adjusts the volume of incoming chat from other players.

Game Volume

Adjusts the game sound volume.

Xbox 360 Talkback Cable Jack

Connect the included Xbox 360 Talkback Cable from this jack

to the Xbox 360 controller.

Bass Boost

Adjusts the intensity of bass boost level applied to the

game audio.

Mic Mute Switch

Switch to MUTE to mute the microphone. The LED will turn

red when the mic is muted and green when the mic is on.

Mic Mute

Switch

Bass

Boost

Xbox 360

Talkback Cable Jack

Game

Volume

Chat

Volume

Using the Ampliﬁer

The DX12 combines two of Turtle Beach’s hottest video gaming audio products into one deluxe combo package. We took

our battle-tested X12 headset and partnered it with the DSS2 surround sound processor that transforms any stereo headset

into a full Dolby

Digital surround sound headset. The result is an amazing recreation of the 3D sound cues in the game,

which sounds as if you’re listening to real surround sound speakers placed all around you. Dolby Digital surround sound lets

you pinpoint the position of sound cues to hear exactly where everything is coming from, so you’ll enjoy a more realistic and

immersive gaming or movie experience.

The Ear Force X12 headset builds on the success of the legendary X11, the most popular Xbox

360 gaming headset of all time,

adding 50mm speakers and adjustable bass for professional-grade sound quality that delivers a competitive advantage. With

the X12, you can hear sound cues that are missed with conventional TV speakers, such as the sound of enemy footsteps or the

click of a loading weapon in the distance. That means you’ll react faster and take them out before they can take you out, giving

you the edge that can make the difference between winning and losing. You’ll also enjoy unsurpassed comfort during extended

game play thanks to the large, deep-cushioned ear cups and rugged, lightweight design.

Mic Mute

LED

Produkspesifikasjoner

Merke:	Turtle Beach
Kategori:	headset
Modell:	Ear Force X12
Produkttype:	Hodesett
Vekt:	233 g
Tilkobling:	USB, 2x3.5mm, 2.5mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Anbefalt bruk:	Spilling
Impedans:	- Ω
Kompatibilitet:	Xbox 360
Dimensjoner (B x D x H):	50.8 x 19 x 12.7 mm
2x 3,5 mm-kontakter:	Ja
Mikrofonfrekvens:	- Hz
Kabellengde:	4.87 m
Produktfarge:	Sort
Hurtigstartsguide:	Ja
Støttede Windows operativsystemer:	Ja
Bæremåte:	Hodebånd
Hodetelefonsfrekvens:	20 - 20000 Hz
Hodetelefonssensitivitet/hodetelefonsfølsomhet:	120 dB
Driverenhet:	50 mm
Hodesett-type:	Stereofonisk
Øresammenkobling:	Circumaural
Magnettype:	Neodym
