Side 1/7

QUICK START GUIDE

GUIDE DE DÉMARRAGE RAPIDE

Vulcan

™

II Mini Air

Vulcan

™

II Mini Air

USB-C to USB-A cable (1.8m)

Câble 1,8 m USB-C vers USB-A

Wireless Dongle

Transmetteur sans-fil USB

TECHNICAL SPECIFICATIONS

■ Connectivity: 2.4GHz Wireless, Bluetooth 5.2,

USB-C to USB-A wired

■ Battery Life: Up to 240 hours with RGB lighting o

■ Cable: Detachable 1.8m / 5.9ft Braided USB-C to USB-A

■ Lighting: RGB Per-Key Illumination

■ Smart Keys: 29

■ Switches: TITAN II Optical

■ Switch Lifecycle: 200M Keystrokes

■ Processor: 32-Bit ARM Cortex M4 Processor

■ Polling Rate: 1000 Hz

■ Adjustable Height: Yes, Double Kickstand

■ Keyboard Rollover: Full Key, Anti-Ghosting

■ On-Board Memory: 4MB

■ Software: Swarm

™

SYSTEM REQUIREMENTS

■ Windows® 10 and above (software support)

■ USB 2.0 (or higher)

■ Internet connection (for driver software)

CONFIGURATION PC REQUISE

■ Windows® 10 et supérieur (support logiciel)

■ USB 2.0 (ou plus)

■ Connexion Internet (pour le logiciel)

SPÉCIFICITÉS TECHNIQUES

■ Connectivité : sans-ﬁl 2,4 GHz, Bluetooth 5.2,

ﬁlaire USB-C vers USB-A

■ Batterie : jusqu‘à 240 heures (RVB désactivé)

■ Câble : USB-C vers USB-A détachable et tressé de 1,8 m / 5,9 ft

■ Éclairage : Illumination RVB touche par touche

■ Touches intelligentes : 29

■ Interrupteurs : TITAN II Optique

■ Durée de vie : 200 millions d‘activation par interrupteur

■ Processeur : ARM Cortex M4 32 bits

■ Taux d‘interrogation : 1000 Hz

■ Hauteur réglable : Oui, deux positions

■ Technologie : Complet, Anti-Ghosting

■ Mémoire embarquée : 4 MB

■ Logiciel : Swarm

™

PACKAGE CONTENTS | CONTENU DE LA BOÎTE

TECHNICAL FACTS | INFORMATIONS TECHNIQUES

The second LED will behave according to smart key function, for more detail install our software.

La seconde LED agira selon les paramètres „Smart Key“. Installez notre logiciel pour plus d‘information.

Top LED, White | LED supérieure, blanc = Caps Lock | VERR. MAJ.

Top LED, Orange | LED supérieure, orange = F112 LOCK | VERR. F1-F12

Bottom LED, light blue | LED inférieure, bleu clair

= Easy-Shif t[+]™ On | Easy-Shif t[+]™ on

STANDARD STANDARD

FN + Shift + ESC FN + Maj. + ECHAP

FN + 6 FN + 6

~ ~

F6 F6

FN + Tab FN + Tab

FN + 8 FN + 8

Switch proﬁle Changement de proﬁl

F8 F8

FN + 2 FN + 2

FN + 0 FN + 0

FN + p FN + p

F2 F2

F10 F10

Scroll Scroll

FN + 4 FN + 4

FN + = FN + =

FN + DEL FN + SUPPR

F4 F4

F12 F12

INS INSER

FN + ESC FN + ECHAP

FN + 5 FN + 5

` `

F5 F5

FN + Caps Lock FN + Verr. Maj.

FN + 7 FN + 7

F112 lock Verrouillage F112

F7 F7

FN + 1 FN + 1

FN + 9 FN + 9

FN + o FN + o

F1 F1

F9 F9

Print Impression

FN + 3 FN + 3

FN + – FN + –

FN + [ FN + [

FN + HOME FN + HOME

F3 F3

F11 F11

Break Break

END FIN

FUNCTION FONCTIONACTION

MEDIA KEY TOUCHE MÉDIA

FN + x FN + xTrack Play/Pause

Lecture/pause de la piste

FN + z FN + z

FN + c FN + c

Skip to backward track Morceau précédent

Skip to forward track Morceau suivant

FUNCTION FONCTIONACTION ACTION

VOLUME KEY TOUCHE DE VOLUME

FN + , FN + ,Volume down Baisse du volume

FN + . FN + .

FN + m FN + m

Volume up Hausse du volume

Audio Mute Mise en sourdine

FUNCTION FONCTIONACTION ACTION

GAME MODE GAME MODE

Caps Lock Verr. Maj.Toggle Easy-Shift[+]™

Activation Easy-Shift[+]™

FN + Win FN + WinToggle Game Mode

Activation du Game Mode

FUNCTION FONCTIONACTION ACTION

LED CONTROL KEY TOUCHE DE CONTRÔLE DES LED

FN + PG up

FN + Cursor right

FN + Cursor up

FN + PG Haut

FN + Droit

FN + Haut

LED brightness up

LED change to next FX

LED change to next

color (full lit only)

Hausse de la luminosité

Mode lumineux des LED suivant

Couleur des LED suivante

(mode rétroéclairage

uniforme uniquement)

FN + CTRL right

FN + PG down

FN + Cursor left

FN + Cursor down

FN + CTRL Droit

FN + PG Bas

FN + Gauche

FN + Bas

LED backlight On/O

LED brightness down

LED change to

previous FX

LED change to previous

color (full lit only)

Rétroéclairage ON/OFF

Baisse de la luminosité

Mode lumineux des LED

Couleur des LED précédente

(en mode rétroéclairage

uniforme uniquement)

FUNCTION FONCTIONACTION ACTION

ACTION

LED INDICATION | INDICATION LED

Additional FN-Layer functionality

(Press FN-key + second key)

(no driver installed)

Couche de fonctionnalité additionnelle

(touche FN + fonction secondaire)

(sans installation de logiciel)

* Smart function: Install required software

and compatible Turtle Beach

™

wireless devices.

Fonctionnalité intelligente : Installez le logiciel requis et

les appareils sans fil compatibles avec Turtle Beach

™

BATTERY STATUS

FN + b

Mice battery life*

FN + v

FN + n

Keyboard battery Life:

Green >30%

Orange 2030%

Red <20%

Blinking Red <10%

FUNCTION ACTION

Headset battery life*

ÉTAT DE LA BATTERIE

FN + b

Autonomie de la souris*

FN + v

FN + n

Autonomie du clavier :

Vert >30 %

Orange 20/30 %

Rouge <20 %

Clignotement rouge <10 %

FONCTION ACTION

Autonomie du casque*

* To pair a device, press and hold for 3 seconds

until the 2nd LED starts breathing.

* Pour l‘appairage, maintenez enfoncée la touche

3 secondes jusqu‘à ce que le 2d voyant clignote.

CONNECTIVITY CONNECTIVITÉ

FN + y

FN + i

FN + y

FN + i

Connect to BT 1 paired* device

Connexion à l‘appareil appairé* en BT 1

Connexion à l‘appareil appairé* en BT 3

FN + t FN + t

FN + u FN + u

Connect to 2.4GHz dongle

Connexion à un dongle 2,4 GHz

Connexion à l‘appareil appairé* en BT 2

FUNCTION FONCTIONACTION ACTION

Connect to BT 2 paired* device

Connect to BT 3 paired* device

On/Off Switch

Interrupteur

Dongle compartment

Compartiment

Produkspesifikasjoner

Merke:	Turtle Beach
Kategori:	Ikke kategorisert
Modell:	Vulcan II Mini Air
Type baklys:	RGB LED
Baklys:	Ja
Bluetooth-versjon:	5.2
USB-kontakttype:	USB Type-A
Tilkoblingsteknologi:	Ledning & Trådløs
Strømkildetype:	Battery, USB
Opprinnelsesland:	China
Pakkevekt:	840 g
Anbefalt bruk:	Spilling
Ladekilde:	USB Type-C
Numerisk tastatur:	Nei
Innebygd minnekapasitet:	4000 KB
Trådløst mottakergrensesnitt:	USB Type-A
Innebygd minne:	Ja
Produkter per pall:	108 stykker
Tastaturdimensjoner (BxDxH):	325 x 124 x 33 mm
Tastaturvekt:	620 g
Justerbar tastaturhøyde:	Ja
Nedlastbar programvare:	Swarm II
Tastaturbatteritype:	Innebygd batteri
Rollover:	N-tast rollover
Kabellengde:	1.8 m
Produktfarge:	Hvit
Pakkedybde:	39.9 mm
Pakkehøyde:	165.1 mm
Pakkebredde:	355.9 mm
Batteriliv (maks.):	240 timer
Kabler inkludert:	USB Type-A - USB Type-C
Pakketype:	Boks
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	8471.60.2000
Enhetsgrensesnitt:	USB + RF Wireless + Bluetooth
Tastaturspråk:	Fransk
Tastaturstil:	Rett
Mus inkludert:	Nei
Støttede Windows operativsystemer:	Windows 10, Windows 11
Tastaturlayout:	AZERTY
Antall medfølgende produkter:	1 stykker
Frekvensbånd og driftskanaler:	2.4 GHz
Prøvingshastighet:	1000 Hz
Fargebehandling overflate:	Monokromatisk
Mottaker medfølger:	Ja
Farge på bakgrunnsbelysning:	Flerfarget
Mottakertype:	Mikromottaker
Masterkassens (ytterkassens) bruttovekt:	5450 g
Masterkassens (ytterkassens) lengde:	375.9 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	199.1 mm
Masterkassens (ytterkassens) høyde:	264.9 mm
Tastaturets formfaktor:	65%
Tangent bevegelse:	3.6 mm
Pekeenhet:	Nei
Tastaturtastbryter:	Opto-mekanisk nøkkelbryter
Tastaturtastenes levetid:	200 millioner tegn
Tastaturets tastebryterteknologi:	TITAN II Red
Avtagbar kabel:	Ja
Anti-dobbeltkontur:	Ja
Tastaturets tasteprofil:	Lavprofil
