Side 1/7

QUICK START GUIDE

GUIDE DE DÉMARRAGE RAPIDE

Vulcan

™

TKL

Vulcan

™

TKL

TECHNICAL FACTS | INFORMATIONS TECHNIQUES

TECHNICAL SPECIFICATIONS

■ Connectivity: USB-A Wired

■ Cable: Detachable USB-A to USB-C 1.8m / 5.9ft

■ Lighting: RGB Per-Key Illumination

■ Switches: TITAN Mechanical

■ Switch Lifecycle: 50M Keystrokes

■ Processor: 32-Bit ARM Cortex M0 Based Processor

■ Polling Rate: 1000 Hz

■ Adjustable Height: Yes, Single Kickstand

■ Keyboard Rollover: Full Keys, Anti-Ghosting

■ On-Board Memory: Yes

■ Software: Swarm

™

SYSTEM REQUIREMENTS

■ Windows® 10 and above (software support)

■ USB 2.0 (or higher)

■ Internet connection (for driver software)

CONFIGURATION PC REQUISE

■ Windows® 10 et supérieur (support logiciel)

■ USB 2.0 (ou plus)

■ Connexion Internet (pour le logiciel)

SPÉCIFICITÉS TECHNIQUES

■ Connectivité : USB-A ﬁlaire

■ Câble : USB-A vers USB-C détachable de 1,8 m / 5,9 ft

■ Éclairage : Illumination RVB touche par touche

■ Interrupteurs : TITAN Mécanique

■ Durée de vie : 50 millions d‘activation par interrupteur

■ Processeur : ARM Cortex M0 32 bits

■ Taux d‘interrogation : 1000 Hz

■ Hauteur réglable : Oui, une position

■ Technologie : Complet, Anti-Ghosting

■ Mémoire embarquée : Oui

■ Logiciel : Swarm

™

PACKAGE CONTENTS | CONTENU DE LA BOÎTE

USB-A to USB-C Cable

Câble USB-A vers USB-C

Additional FN-Layer functionality

(Press FN-key + second key)

Couche de fonctionnalité additionnelle

(touche FN + fonction secondaire)

STANDARD

FN + F10

FN + DEL

Stop

Toggle change F9 – F12

secondary and main

functions

FN + F12

FN + Right Ctrl

Skip to forward track

Toggle LEDs On/O

FN + Arrows Right

FN + Arrows Down

FN + Arrows Left

Cycle RGB Eects

LED Brightness Down

Cycle RGB Eects

FN + HOME Scroll

FN + F9

FN + Page Up

Skip to backward track

Pause

FN + F11 Track Play/Pause

FN + Arrows Up LED Brightness Up

FN + INS Print Screen

FUNCTION ACTION

FN + Page Down Toggle Game Mode

FN + END Swap Win key and Fn

key function

FN + PAGE BAS Activation du Game Mode

FN + FIN Intervertir les fonctions des

touches Windows et FN

STANDARD

FN + F10

FN + SUPPR

Stop

Basculement entre les

fonctions principales et

secondaires F9-F12

FN + F12

FN + Ctrl Droit

Morceau suivant

Allumer/éteindre le

rétroéclairage LED

FN + Arrows Droit

FN + Flèche du bas

FN + Arrows Gauche

Mode lumineux des LED

Réduire la luminosité

du rétroéclairage

Mode lumineux des LED

FN + DÉBUT Scroll

FN + F9

FN + PAGE HAUT

Morceau précédent

Pause

FN + F11 Lecture/pause de la piste

FN + Flèche du haut Augmenter la luminosité

du rétroéclairage

FN + INSER Impression

FONCTION ACTION

ADDITIONAL FN-LAYER FUNCTIONALITY

COUCHE DE FONCTIONNALITÉ ADDITIONNELLE

ADDITIONAL FN-LAYER FUNCTIONALITY

COUCHE DE FONCTIONNALITÉ ADDITIONNELLE

Caps Lock Verr. Maj.Toggle Easy-Shift[+]™ Activation Easy-Shift[+]™

Produkspesifikasjoner

Merke:	Turtle Beach
Kategori:	Ikke kategorisert
Modell:	Vulcan TKL
Type baklys:	RGB LED
Baklys:	Ja
LED-indikatorer:	Ja
USB-kontakttype:	USB Type-A
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	USB
Opprinnelsesland:	China
Pakkevekt:	961 g
Antall farger:	16.8 M
Anbefalt bruk:	Spilling
Numerisk tastatur:	Nei
Innebygd minne:	Ja
Tastaturdimensjoner (BxDxH):	360 x 133.25 x 34 mm
Tastaturvekt:	660 g
Justerbar tastaturhøyde:	Ja
Kabellengde:	1.8 m
Produktfarge:	Sort
Pakkedybde:	44 mm
Pakkehøyde:	173 mm
Pakkebredde:	384 mm
Kabler inkludert:	USB Type-A - USB Type-C
Pakketype:	Boks
Harmonisert system (HS)-kode:	8471.60.2000
Enhetsgrensesnitt:	USB
Tastaturspråk:	Fransk
Tastaturstil:	Rett
Mus inkludert:	Nei
Tastaturlayout:	AZERTY
Antall medfølgende produkter:	1 stykker
Prøvingshastighet:	1000 Hz
Fargebehandling overflate:	Monokromatisk
Farge på bakgrunnsbelysning:	Flerfarget
Masterkassens (ytterkassens) bruttovekt:	6100 g
Masterkassens (ytterkassens) lengde:	402 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	289 mm
Masterkassens (ytterkassens) høyde:	200 mm
Tastaturets formfaktor:	Tenkeyless (80 - 87og)
Tangent bevegelse:	3.6 mm
Justerbart baklys:	Ja
Pekeenhet:	Nei
Tastaturtastbryter:	Mekanisk nøkkelbryter
Tastaturtastenes levetid:	50 millioner tegn
Avtagbar kabel:	Ja
Tastaturets tasteprofil:	Lavprofil
