V-Tac VT-10183 Bruksanvisning
Les nedenfor 📖 manual på norsk for V-Tac VT-10183 (3 sider) i kategorien belysning. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 1.5 brukere
Side 1/3
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
SOLAR LED GARDEN LIGHT
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-10183
SKU 23996
SOLAR PANEL
DC: 5V, 1.3W
Monocrystal
LUMENS 100 lm
BEAM ANGLE 80°
NET WEIGHT 247g
DIMENSION
175x125x114mm
310x175x114mm (with spike)
BATTERY CHARGING TIME WORKING TIME
DC: 3.7V, 1200mAh, Li-Ion 6-8 Hours 10-12 Hours
INSTALLATION INSTRUCTIONS
Spike Installation
Wall Installation
1
3
2
2
1 3
WARNING
1. Please make sure to turn o the power before
starting the installation.
2. Installation should be done by certified electrician.
3. The light source of this luminaire is not replace-
able; when the light source reaches its end of life
the whole luminaire shall be replaced.
This marking indicates that this
product should not be disposed
of with other household wastes.
TYPE 1: SPIKE INSTALLATION
• Adjust the angle of the lamp body to achieve the desired direction.
• Secure the ground spike bracket firmly in place.
• Position the device in a suitable lawn area, ensuring stability and proper placement.
• Verify the installation for accuracy, then press the switch button to activate the lamp.
TYPE 2: WALL INSTALLATION
• Disassemble the pole and securely install it onto the wall using screws.
• Reattach the lamp body and fasten it with nuts, adjusting the angle as needed.
• Verify the installation for accuracy, then press the switch button to activate the lamp.
2
3
OFF/ON
2
OFF/ON
