Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL

Table of Contents C

opyright 2017 Vestil Manufacturing Co. Page 1 of 13

LAD-MM Series Mobile Ladder Stands

Instruction Manual

Receiving instructions:

After delivery, remove the packaging from the product. Inspect the product closely to determine whether

it sustained damage during transport. If damage is discovered, record a complete description of it on the

bill of lading. If the product is undamaged, discard the packaging.

NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply

with laws, regulations, codes, and mandatory standards applied where the product is used.

Replacement Parts and Technical Assistance:

For answers to questions not addressed in these instructions and to order replacement parts, labels,

and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can

also be contacted online at http://www.vestilmfg.com/parts_info.htm

Table of Contents

Specifications…………..…………………….………………………………………………………………………..…. 2

Signal Words………….……................................................................................................................................ 3

Hazards of Using the Ladder………………………..………………………………………………………………….. 3

Exploded Views and Bills of Materials…..……………………………………………………………..................4 – 8

LAD-MM-(2; 3; & 4)-(P & G)…………………………………………………………………………………………. 4

LAD-MM-(5; 6; & 7)-(P & G)…………………………………………………………………………………………. 5

LAD-MM-(8; 9; & 10)-(P &G)………………………………………………………………………………………… 6

LAD-MM-11-(P & G)………………………………………………………………………………………………….. 7

LAD-MM-12-(P & G)………………………………………………………………………………………………….. 8

Assembling the Ladder…..………………………………………………………………………………………9, 10, 11

Using the Ladder……..…………..…………………………………………………………………………………….. 11

Record of Normal Condition…………………………………………………………………………………………… 12

Inspections & Maintenance…………................................................................................................................. 12

Labeling Diagram………...…............................................................................................................................. 12

Limited Warranty…………...…………………………………………………………………………………………… 13

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
