Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL
Table of Contents C
opyright 2017 Vestil Manufacturing Co. Page 1 of 13
LAD-MM Series Mobile Ladder Stands
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether
it sustained damage during transport. If damage is discovered, record a complete description of it on the
bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Assistance:
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can
also be contacted online at http://www.vestilmfg.com/parts_info.htm
.
Table of Contents
Specifications…………..…………………….………………………………………………………………………..…. 2
Signal Words………….……................................................................................................................................ 3
Hazards of Using the Ladder………………………..………………………………………………………………….. 3
Exploded Views and Bills of Materials…..……………………………………………………………..................4 – 8
LAD-MM-(2; 3; & 4)-(P & G)…………………………………………………………………………………………. 4
LAD-MM-(5; 6; & 7)-(P & G)…………………………………………………………………………………………. 5
LAD-MM-(8; 9; & 10)-(P &G)………………………………………………………………………………………… 6
LAD-MM-11-(P & G)………………………………………………………………………………………………….. 7
LAD-MM-12-(P & G)………………………………………………………………………………………………….. 8
Assembling the Ladder…..………………………………………………………………………………………9, 10, 11
Using the Ladder……..…………..…………………………………………………………………………………….. 11
Record of Normal Condition…………………………………………………………………………………………… 12
Inspections & Maintenance…………................................................................................................................. 12
Labeling Diagram………...…............................................................................................................................. 12
Limited Warranty…………...…………………………………………………………………………………………… 13
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com Email: info@vestil.com
Table of Contents Rev. 12.6.2018 LAD-MM, MANUAL
Table of Contents C
opyright 2017 Vestil Manufacturing Co. Page 2 of 13
Specifications:
Dimensions and other relevant specifications for each LAD-MM series ladder stand appear in the table
below.
Model
Number of
steps
A:
Overall
height
B:
Overall
width
C:
Railing
height
D:
Platform
height
E:
Usable
length
F:
Overall
length
Step
slope
Capacity
Net
Weight
LAD-MM-2-P
2
50”
29
1
/
2
”
30”
20”
27
1
/
4
”
38
1
/
2
”
58°
350 lb.
69 lb.
LAD-MM-3-P
3 60” 29
1
/
2
” 30” 30” 33
1
/
2
” 38
7
/
16
” 58° 350 lb. 82 lb.
LAD-MM-4-P
4
70”
29
1
/
2
”
30”
40”
39
3
/
4
”
42
5
/
8
”
58°
350 lb.
100 lb.
LAD-MM-5-P
5 80” 29
1
/
2
” 30” 50” 46” 49
3
/
4
” 58° 350 lb. 119 lb.
LAD-MM-6-P
6
90”
29
1
/
2
”
30”
60”
52
1
/
4
”
56
11
/
16
”
58°
350 lb.
135 lb.
LAD-MM-7-P 7 100” 29
1
/
2
” 30” 70” 58
1
/
2
” 62
3
/
8
” 58° 350 lb. 150 lb.
LAD-MM-8-P
8 110” 29
1
/
2
” 30” 80” 64
3
/
4
” 68
5
/
8
” 58° 350 lb. 169 lb.
LAD-MM-9-P
9 120” 29
1
/
2
” 30” 90” 71” 74
7
/
8
” 58° 350 lb. 185 lb.
LAD-MM-10-P
10 130” 29
1
/
2
” 30” 100” 77
1
/
4
” 81
1
/
8
” 58° 350 lb. 202 lb.
LAD-MM-11-P
11
140”
32”
30”
110”
83
1
/
2
”
87
3
/
8
”
58°
350 lb.
222 lb.
LAD-MM-12-P
12 156” 32” 36” 120” 89
3
/
4
” 93
1
/
4
” 58° 350 lb. 247 lb.
LAD-MM-2-G
2
50”
29
1
/
2
”
30”
20”
27
1
/
4
”
38
1
/
2
”
58°
350 lb.
70 lb.
LAD-MM-3-G
3 60” 29
1
/
2
” 30” 30” 33
1
/
2
” 38
1
/
2
” 58° 350 lb. 84 lb.
LAD-MM-4-G
4
70”
29
1
/
2
”
30”
40”
39
3
/
4
”
43
5
/
8
”
58°
350 lb.
101 lb.
LAD-MM-5-G 5 80” 29
1
/
2
” 30” 50” 46” 49
3
/
4
” 58° 350 lb. 121 lb.
LAD-MM-6-G
6 90” 29
1
/
2
” 30” 60” 52
1
/
4
” 56
11
/
16
” 58° 350 lb. 137 lb.
LAD-MM-7-G 7 100” 29
1
/
2
” 30” 70” 58
1
/
2
” 62
3
/
8
” 58° 350 lb. 152 lb.
LAD-MM-8-G
8 110” 29
1
/
2
” 30” 80” 64
3
/
4
” 68
5
/
8
” 58° 350 lb. 172 lb.
LAD-MM-9-G
9 120” 29
1
/
2
” 30” 90” 71” 74
7
/
8
” 58° 350 lb. 188 lb.
LAD-MM-10-G
10 130” 29
1
/
2
” 30” 100” 77
1
/
4
” 81
1
/
8
” 58° 350 lb. 205 lb.
LAD-RF-11-G
11
140”
32”
30”
110”
83
1
/
2
”
87
3
/
8
”
58°
350 lb.
225 lb.
LAD-RF-12-G
12 156” 32” 36” 120” 89
3
/
4
” 93
1
/
4
” 58° 350 lb. 250 lb.
