Viewsonic CDE5010 Bruksanvisning

Viewsonic skjerm CDE5010

Les nedenfor 📖 manual på norsk for Viewsonic CDE5010 (72 sider) i kategorien skjerm. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/72

CDE5010

Commercial Display

User Guide

Model No. VS17539

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specific languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic

As a world leading provider of visual solutions, ViewSonic is dedicated to

exceeding the world’s expectations for technological evolution, innovation, and

simplicity. At ViewSonic, we believe that our products have the potential to

make a positive impact in the world, and we are condent that the ViewSonic

product you have chosen will serve you well.

Once again, thank you for choosing ViewSonic !

Compliance Information

NOTE: This section addresses all connected requirements and statements regarding regulations.

Confirmed corresponding applications shall refer to nameplate labels and relevant markings on

unit.

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his/her own

expense.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: To comply with the limits for the Class A digital device, pursuant to Part 15 of the FCC

Rules, this device must be installed in computer equipment certified to comply with the Class A

limits. All cables used to connect the computer and peripherals must be shielded and grounded.

Operation with non-certified computers or non-shielded cables may result in interference to radio or

television reception. Changes and modifications not expressly approved by the manufacturer could

void the user’s authority to operate this equipment.

CAN ICES-3 (A)/NMB-3(A)

WARNING: This equipment is compliant with Class A of EN55032.In a residential environment this

equipment may cause radio interference.

CE Conformity for European Countries

The device complies with the EMC Directive 2014/30/EU and Low Voltage Directive

2014/35/EU.

WARNING: This equipment is compliant with Class A of EN55032.In a residential environment this

equipment may cause radio interference.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	CDE5010
Vekt:	13000 g
Bredde:	1123.6 mm
Dybde:	67.8 mm
Høyde:	646.7 mm
Prosessorfamilie:	ARM Cortex
Intern lagringskapasitet:	8 GB
USB-port:	Ja
Synsvinkel, horisontal:	178 °
Pakkevekt:	16500 g
Antall HDMI-porter:	2
DVI-port:	Ja
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Strømforbruk (maks.):	175 W
USB-versjon:	3.2 Gen 1 (3.1 Gen 1)
Internminne:	2 GB
HDMI-versjon:	2.0
Skjermteknologi:	LED
Bruttovekt:	16500 g
Vekt (med stativ):	14900 g
On Screen Display (OSD):	Ja
Vekt (imperial):	32.9 Ibs
Produktvekt:	28.7 Ibs
Kontrastforhold:	4000:1
Produktdesign:	Digital skiltingstavle (flatskjerm)
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 / 60 Hz
Skjermoppløsning:	3840 x 2160 piksler
Strømforbruk (standby):	0.5 W
Lydinngang (mini-jack):	Ja
Produktfarge:	Sort
Antall USB-porter:	2
HD-type:	4K Ultra HD
Bredde (med stativ):	1123.6 mm
Dybde (med stativ):	329.6 mm
Høyde (med stativ):	685.9 mm
Pakkedybde:	203 mm
Pakkehøyde:	845 mm
Pakkebredde:	1282 mm
Prosessorkjerner:	4
Minnekortenhet:	MicroSD (TransFlash)
Skjermdiagonal:	50 "
Antall DVI-D-porter:	1
Kabler inkludert:	AC, IR sensor, RS-232, VGA
Strømforbruk (vanlig bruk):	140 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	ENERGY STAR
Innebygd kortleser:	Ja
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Synsvinkel, vertikal:	178 °
Samsvar med industristandarder:	cULus, FCC, UL-MX-CoC, Mexico Energy
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 80
Prosessormodell:	A53
Lysstyrke for skjerm:	350 cd/m²
Oppdateringsresponstid:	8 ms
Panelliv:	30000 timer
Inngangsporter for VGA (D-Sub):	1
RS-232-tilkobling:	Ja
Panelmonterbart grensesnitt:	400 x 400 mm
RMS-rangert strøm/utgangseffekt:	20 W
Fjern (IR)-utgang:	1
Støttede plasseringer/plasseringer som kan benyttes:	Innendørs
Brukerguide på CD-ROM:	Ja
LED-baklystype:	Direct-LED
Formål:	Bedrift
Fjerninngang (IR):	1
Sett bredde (tommer):	44.2 "
Sett høyde (tommer):	27 "
Sett dybde (tommer):	13 "
