Viewsonic VP2458 Bruksanvisning

Viewsonic skjerm VP2458

Les nedenfor 📖 manual på norsk for Viewsonic VP2458 (75 sider) i kategorien skjerm. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/75

VP2458

Monitor

User Guide

Model No. VS17557

P/N: VP2458

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in

a safe manner, as well as registering your product for future service. Warranty information contained in this User

Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website.

Thank you for choosing ViewSonic®

As a world-leading provider of visual soluons, ViewSonic® is dedicated to exceeding

the world’s expectaons for technological evoluon, innovaon, and simplicity. At

ViewSonic®, we believe that our products have the potenal to make a posive

impact in the world, and we are condent that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precauons

Please read the following Safety Precautions before you start using the device.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instrucons.

• Sit at least 18" (45 cm) away from the device.

• Allow at least 4" (10 cm) clearance around the device to ensure proper

venlaon.

• Place the device in a well-venlated area. Do not place anything on the device

that prevents heat dissipaon.

• Do not use the device near water. To reduce the risk of re or electric shock, do

not expose the device to moisture.

• Avoid exposing the device to direct sunlight or other sources of sustained heat.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other devices (including ampliers) that may increase the temperature of the

device to dangerous levels.

• Use a so, dry cloth to clean the external housing. For more informaon, refer to

the "Maintenance" secon on page 62.

• Oil may collect on the screen as you touch it. To clean the greasy spots on the

screen, refer to the "Maintenance" secon on page 62.

• Do not touch the screen surface with sharp or hard objects, as it may cause

damage to the screen.

• When moving the device, be careful not to drop or bump the device on anything.

• Do not place the device on an uneven or unstable surface. The device may fall

over resulng in an injury or a malfuncon.

• Do not place any heavy objects on the device or connecon cables.

• If smoke, an abnormal noise, or a strange odor is present, immediately turn the

device o and call your dealer or ViewSonic®. It is dangerous to connue using

the device.

• Do not aempt to circumvent the safety provisions of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding-type plug has two blades and a third grounding prong. The

wide blade and the third prong are provided for your safety. If the plug does not

t into your outlet, obtain an adapter and do not aempt to force the plug into

the outlet.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VP2458
Farge:	Sort
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Opprinnelsesland:	China
Pakkevekt:	8600 g
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Nei
Sertifisering:	cTUVus, FCC-B, ICES003, MX-CoC, Mexico Energy
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
HDMI:	Ja
HDMI-versjon:	1.4
Skjermteknologi:	LED
Kontrastforhold (dynamisk):	20000000:1
Innebygd kamera:	Nei
Antall DisplayPorts:	1
Energiforbruk (HDR) per 1000 timer:	- kWh
Energieffektivitetsklasse (SDR):	E
Energiforbruk (SDR) per 1000 timer:	16 kWh
Vekt (med stativ):	5500 g
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
Fargedybde:	6 bit
On Screen Display (OSD):	Ja
Antall USB Type-A nedstrømsporter:	2
Innebygd USB-hub:	Ja
Flimmerfri teknologi:	Ja
Antall oppstrømsporter:	1
DisplayPort-versjon:	1.2
Kontrastforhold:	1000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	0.3 W
Høydejustering:	Ja
Produktfarge:	Sort
sRGB-dekning (typisk):	100
HD-type:	Full HD
Vippevinkelområde:	-5 - 21 °
USB-hub-versjon:	3.2 Gen 1 (3.1 Gen 1)
Bredde (uten stativ):	539 mm
Høyde (uten stativ):	311 mm
Vekt (uten stativ):	3100 g
Bredde (med stativ):	539 mm
Dybde (med stativ):	215 mm
Høyde (med stativ):	423.7 mm
Pakkedybde:	380 mm
Pakkehøyde:	205 mm
Pakkebredde:	690 mm
Skjermdiagonal:	23.8 "
Naturlig sideforhold:	16:9
Hodetelefon ut:	Nei
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Kabler inkludert:	AC, DisplayPort, USB
Horisontalt frekvensområde:	55 - 90 kHz
Strømforbruk (vanlig bruk):	17.5 W
Antall VGA (D-Sub)-porter:	1
Strøminngang/AC (strøm) inn:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85285210
VESA-montering:	Ja
Dybde (uten stativ):	48 mm
Paneltype:	AH-IPS
Svingvinkel:	-90 - 90 °
Synsvinkel, vertikal:	178 °
Diagonal skjermstørrelse:	60.45 cm
Relativ luftfuktighet under drift (H-H):	20 - 90
Oppdateringsresponstid:	5 ms
Pikselbredde:	0.275 x 0.275 mm
Antall OSD språk:	14
Panelmonterbart grensesnitt:	100 x 100 mm
Markedsplassering:	Forretning
Skjermlysstyrke (typisk):	250 cd/m²
Display antall farger:	1,67 milliarder farger
Kabellåsport:	Ja
Fremre ramme:	Sort
Avtagbart stativ:	Ja
Low Blue Light-teknologi:	Ja
Vippjustering:	Ja
Europeisk produktregister for energimerking (EPREL-kode):	356062
Bildestørrelse, horisontal:	527 mm
Bildestørrelse, vertikal:	296 mm
Vertikal scanningsratio:	48 - 74 Hz
Kabellåstype:	Kensington
Anti-blendende skjerm:	Ja
Dreibar:	Ja
Dreietapp/dreiemekanisme:	0 - 120 °
Omdreiningsakse/midtpunkt:	Ja
Strømforbruk, av:	0.3 W
Lydkontakter:	Nei
Strømforbruk, strømsparing:	11.5 W
Plugg inn og spill:	Ja
USB oppstrømsporttype:	USB Type-B
Rammeløst design:	Ja
NTSC-dekning (typisk):	72.57
