Side 1/63

CDM4300R/CDM4900R/CDM5500R

Commercial Display

User Guide

Model No. VS16466/VS16467/VS16468

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specific languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic

With over 25 years as a world leading provider of visual solutions, ViewSonic is

dedicated to exceeding the world’s expectations for technological evolution,

innovation, and simplicity. At ViewSonic, we believe that our products have

the potential to make a positive impact in the world, and we are confident

that the ViewSonic product you have chosen will serve you well.

Once again, thank you for choosing ViewSonic !

Compliance Information

NOTE: This section addresses all connected requirements and statements regarding regulations.

Confirmed corresponding applications shall refer to nameplate labels and relevant markings on

unit.

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

For Canada

CAN ICES-3 (A)/NMB-3(A)

Industry Canada Notice

This device complies with Canadian RSS-210.To prevent radio interference to the licensed service,

this device is intended to be operated indoors and away from windows to provide maximum

shielding. Equipment (or its transmitting antenna) that is installed outdoors is subject to licensing.

The installer of this radio equipment must ensure that the antenna is located or pointed such that it

does not emit RF field in excess of Health Canada limits for the general population; consult Safety

Code 6, obtainable from Health Canada’s website www.hc-sc.gc.ca/rpb.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	CDM5500R
Vekt:	22000 g
Bredde:	1233 mm
Dybde:	45.5 mm
Høyde:	710 mm
Bruksanvisning:	Ja
Wi-Fi:	Ja
Synsvinkel, horisontal:	178 °
Pakkevekt:	24.3 kg
Antall HDMI-porter:	2
DVI-port:	Ja
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Sertifisering:	UL/cUL, FCC, UL-MX-CoC, Mexico Energy
RS-232C:	Ja
USB-versjon:	2.0
Internminne:	16 GB
HDMI-versjon:	1.4
Skjermteknologi:	LED
Datasystem:	Ja
Antall DisplayPorts:	2
On Screen Display (OSD):	Ja
Kontrastforhold:	1100:1
Produktdesign:	Digital skiltingstavle (flatskjerm)
AC-inngangsspenning:	100 - 240 V
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	0.5 W
Skjermoverflate:	Matt
Produktfarge:	Sort
Antall USB-porter:	2
HD-type:	Full HD
Vekt (uten stativ):	18000 g
Pakkedybde:	223 mm
Pakkehøyde:	952 mm
Pakkebredde:	1448 mm
Prosessorkjerner:	4
Minnekortenhet:	SD
Skjermdiagonal:	55 "
Naturlig sideforhold:	16:9
Kabler inkludert:	AC, IR sensor, RS-232
Strømforbruk (vanlig bruk):	75 W
Lydinngang (V/H) inn:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	ENERGY STAR
Innebygd kortleser:	Ja
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Synsvinkel, vertikal:	178 °
Antall DVI-I-porter:	2
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
Prosessormodell:	RK3188
Lysstyrke for skjerm:	450 cd/m²
Oppdateringsresponstid:	12 ms
Pikselbredde:	- mm
Panelliv:	- timer
Lydutgang (venstre/høyre):	1
Panelmonterbart grensesnitt:	400 x 400 mm
RMS-rangert strøm/utgangseffekt:	20 W
Innebygd TV-mottaker:	Nei
LED-baklystype:	Direct-LED
