Side 1/19

ViewSonic

- User Guide

- 使用手冊

ViewSonic

G220f/G220fB/G220fSB

CRT Monitor

Model No. : VS11235

ViewSonic G220f/G220fB/G220fSB

Contents

TCO Information ............................................................................................. i

Important Safety Instructions .......................................................................... 1

Product Registration ........................................................................................ 2

Getting Started

Package Contents ........................................................................................... 3

Precautions ..................................................................................................... 3

Quick Installation ............................................................................................. 4

Using the Monitor

Setting the Timing Mode ................................................................................. 5

OSD Lock Settings .......................................................................................... 5

Adjusting the Screen Image ............................................................................ 6

Main Menu Controls ........................................................................................ 8

Other Information

Speciﬁcations .................................................................................................. 11

Troubleshooting .............................................................................................. 12

Customer Support ........................................................................................... 13

Cleaning the Monitor ....................................................................................... 14

Limited Warranty ............................................................................................. 15

ViewSonic G220f/G220fB/G220fSB

TCO Information

Congratulations!

The display you have just purchased carries the TCO’03 Displays

label. This means that your display is designed, manufactured and

tested according to some of the strictest quality and environmental

requirements in the world. This makes for a high performance product,

designed with the user in focus that also minimizes the impact on our

natural environment.

Some of the features of the TCO’03 Display requirements:

Ergonomics

• Good visual ergonomics and image quality in order to improve the working environment

for the user and to reduce sight and strain problems. Important parameters are luminance,

contrast, resolution, reﬂectance, color rendition and image stability.

Energy

• Energy-saving mode after a certain time – beneficial both for the user and the

environment

• Electrical safety

Emissions

• Electromagnetic ﬁelds

• Noise emissions

Ecology

• The product must be prepared for recycling and the manufacturer must have a certiﬁed

environmental management system such as EMAS or ISO 14 000

• Restrictions on

o chlorinated and brominates ﬂame retardants and polymers

o heavy metals such as cadmium, mercury and lead.

The requirements included in this label have been developed by TCO Development in

cooperation with scientists, experts, users as well as manufacturers all over the world. Since

the end of the 1980s TCO has been involved in inﬂuencing the development of IT equipment

in a more user-friendly direction. Our labeling system started with displays in 1992 and is now

requested by users and IT-manufacturers all over the world.

For more information, please visit

www.tcodevelopment.com

* This declaration is for TCO’03 compliance model.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	G220f
Vekt:	27000 g
Strømkilde:	AC 90-264V, 50/60 Hz (auto switch)
Sertifisering:	TCO'99, TMV/GS, TMV-ERGO, CE, ISO9241-3, ISO9241-7, ISO9241-8, Energy 2000, MPR-II, CE, CB, UL, FCC-B, DHHS, VCCI, C-TICK, NOM, SASO, CSA, DOC-B, NEMKO, DEMKO, SEMKO, FIMKO, B-Mark, PCT, CCIB, S-Mark, IRAM, ICE5003, CCEE, EMC, EMI-B
Kompatible produkter:	PC und Mac compatible
Dimensjoner (B x D x H):	500 x 488 x 508 mm
Skjermoppløsning:	1600 x 1200 piksler
Skjermdiagonal:	21 "
Horisontalt frekvensområde:	30 - 110 kHz
Strømforbruk (vanlig bruk):	115 W
Modell/Type:	21" (20.0" viewable) 90° deflection
Monteringsgrensesnitt:	Plug & Play
I/O-porter:	Signal - 15-pin mini D-Sub (attached) \nPower - 3-pin plug (IEC 320)\n
Lydsystem:	Nei
Relativ luftfuktighet under drift (H-H):	5 - 95
Pikselbredde:	0.25 mm
Bildestørrelse, horisontal:	400 mm
Bildestørrelse, vertikal:	300 mm
Vertikal scanningsratio:	50 - 180 Hz
Kompatibel med Mac:	Ja
Strømfunksjoner:	Meets ENERGY STAR, VESA DPMS, TCO '99 and Energy 2000 standards
Type skjermteknologi:	Tint (TM=50%), ARAG screen treatment
