Side 1/139

IFP50-3 Series

Commercial Touch Display

User Guide

Model No. VS18105/VS18106/VS17117/VS17118

IFP8650-3|IFP8650-3A|IFP8650-3B

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in

a safe manner, as well as registering your product for future service. Warranty information contained in this User

Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic®

As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding

the world’s expectations for technological evolution, innovation, and simplicity.

At ViewSonic®, we believe that our products have the potential to make a positive

impact in the world, and we are confident that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

^ĂĨĞƚǇWƌĞĐĂƵƟŽŶƐ

Please read the following ^ĂĨĞƚǇWƌĞĐĂƵƟŽŶƐ before you start using the device.

•

Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instructions.

• Do not use the device near water. To reduce the risk of fire or electric shock, do

not expose the device to moisture.

• Never remove the rear cover. This display contains high-voltage parts. You may

be seriously injured if you touch them.

• Avoid exposing the device to direct sunlight or other sources of sustained heat.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other devices (including amplifiers) that may increase the temperature of the

device to dangerous levels.

• Use a soft, dry cloth to clean the external housing. For more information, refer

to the "Maintenance" section on page 127.

• When moving the device, be careful not to drop or bump the device on

anything.

• Do not place the device on an uneven or unstable surface. The device may fall

over resulting in an injury or a malfunction.

• Do not place any heavy objects on the device or connection cables.

• If smoke, an abnormal noise, or a strange odor is present, immediately turn the

device off and call your dealer or ViewSonic®. It is dangerous to continue using

the device.

• The device is a monitor with an LED backlight intended for general office use.

• Do not attempt to circumvent the safety provisions of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding-type plug has two blades and a third grounding prong. The

wide blade and the third prong are provided for your safety. If the plug does not

fit into your outlet, obtain an adapter and do not attempt to force the plug into

the outlet.

• When connecting to a power outlet, DO NOT remove the grounding

prong. Please ensure grounding prongs are NEVER REMOVED.

• Protect the power cord from being treaded upon or pinched,

particularly at the plug, and at the point where it emerges from

the equipment. Ensure that the power outlet is located near the

equipment so that it is easily accessible.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	IFP6550-E1
Vekt:	53400 g
Bredde:	1521 mm
Dybde:	145 mm
Høyde:	992 mm
Berøringsskjerm:	Ja
Prosessorfrekvens:	1.2 GHz
Prosessorfamilie:	ARM Cortex
Intern lagringskapasitet:	16 GB
Wi-Fi:	Ja
USB-port:	Ja
Synsvinkel, horisontal:	178 °
Pakkevekt:	67100 g
Antall HDMI-porter:	3
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Teknologi:	Infrarød (IR)
Strømforbruk (maks.):	350 W
Sertifisering:	cTUVus, FCC, Mexico Energy, CE, CB, ErP, WEEE
USB-versjon:	2.0/3.2 Gen 1 (3.1 Gen 1)
Internminne:	2 GB
Skjermteknologi:	LED
Datasystem:	Nei
Antall DisplayPorts:	1
Innebygd subwoofer:	Ja
On Screen Display (OSD):	Ja
Hardhet:	7H
Forhåndsinstallert programvare:	ViewSonic Wizard CD
Antall samtidige berøringspunkter:	20
Kontrastforhold:	1200:1
Produktdesign:	Digital skiltingstavle (flatskjerm)
AC-inngangsspenning:	100 - 240 V
Skjermoppløsning:	3840 x 2160 piksler
Strømforbruk (standby):	0.5 W
Antall pekepenner:	3
Produktfarge:	Sort
Antall USB-porter:	6
HD-type:	4K Ultra HD
Pakkedybde:	285 mm
Pakkehøyde:	1071 mm
Monteringssett:	Ja
Pakkebredde:	1697 mm
Prosessorkjerner:	4
Skjermdiagonal:	65 "
Berøringsteknologi:	Multi-touch
Berøringsskjermtype:	Infrarød
Naturlig sideforhold:	16:9
Operativsystemprogramvare 04:	Android 7.0
Kabler inkludert:	AC, Audio (3.5mm), USB, VGA
Strømforbruk (vanlig bruk):	350 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	RoHS, ENERGY STAR
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Montering:	WMK-047-2
Synsvinkel, vertikal:	178 °
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
Prosessormodell:	A53
Lysstyrke for skjerm:	350 cd/m²
Oppdateringsresponstid:	8 ms
Pikselbredde:	- mm
Inngangsporter for VGA (D-Sub):	1
Komposittvideo inn/sammensatt video inn:	1
Antall HDMI-utgangsporter:	1
RS-232-tilkobling:	Ja
Panelmonterbart grensesnitt:	600 x 400 mm
RMS-rangert strøm/utgangseffekt:	20 W
Batterier medfølger:	Ja
Innebygd TV-mottaker:	Nei
Støttede plasseringer/plasseringer som kan benyttes:	Inne/Ute
Formål:	Utdanning
Subwoofer RMS-styrke:	15 W
Pekepenn:	Ja
Kompatibel veggmontering:	WMK-047-2
