Side 1/25

SD-Z245

Zero Client Monitor

User Guide

Model No. VS15612

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Compliance Information

NOTE: This section addresses all connected requirements and statements regarding

regulations. Confirmed corresponding applications shall refer to nameplate labels

and relevant markings on unit.

FCC Compliance Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy, and if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modifications not expressly approved

by the party responsible for compliance could void your authority to operate the

equipment.

Industry Canada Statement

CAN ICES-3(B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage

Directive 2006/95/EC.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and

Electronic Equipment Directive 2002/96/EC (WEEE).The mark indicates

the requirement NOT to dispose the equipment as unsorted municipal

waste, but use the return and collection systems according to local law.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	SD-Z245
Type baklys:	W-LED
LED-indikatorer:	Kraft indikator
Berøringsskjerm:	Nei
Prosessorfamilie:	Teradici
Synsvinkel, horisontal:	170 °
Pakkevekt:	6600 g
DVI-port:	Ja
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Hodetelefonutganger:	1
Sertifisering:	FCC, CB, cTUVus, WEEE, RoHS, REACH
USB-versjon:	2.0
Internminne:	512 MB
3D:	Nei
Skjermteknologi:	LCD
Digital horisontal frekvens:	24 - 82 kHz
Digital vertikal frekvens:	50 - 75 Hz
Kontrastforhold (dynamisk):	20000000:1
Innebygd kamera:	Nei
Vekt (med stativ):	5100 g
On Screen Display (OSD):	Ja
Antall USB Type-A nedstrømsporter:	4
Tynn klient installert:	Ja
Kontrastforhold:	1000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Høydejustering:	Nei
Produktfarge:	Sort
HD-type:	Full HD
Vippevinkelområde:	-5 - 20 °
USB-hub-versjon:	2.0
Bredde (uten stativ):	566.4 mm
Høyde (uten stativ):	345.4 mm
Vekt (uten stativ):	3900 g
Bredde (med stativ):	566.4 mm
Dybde (med stativ):	189.9 mm
Høyde (med stativ):	392.7 mm
Pakkedybde:	158 mm
Pakkehøyde:	467 mm
Pakkebredde:	630 mm
Internminnetype:	DDR3
Skjermdiagonal:	24 "
Naturlig sideforhold:	16:9
Hodetelefontilkobling:	3,5 mm
Hodetelefon ut:	Ja
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Separat H/V-synkronisering:	Ja
Kabler inkludert:	AC, VGA
Strømforbruk (vanlig bruk):	28 W
Støttede videofunksjoner:	1080p
Antall VGA (D-Sub)-porter:	1
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 35 °C
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	48 mm
Paneltype:	TFT
Synsvinkel, vertikal:	160 °
DC-inngangskontakt:	Ja
Av/på-bryter:	Ja
Antall DVI-I-porter:	1
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	15 - 90
Prosessormodell:	Tera2321
Oppdateringsresponstid:	5 ms
Panelmonterbart grensesnitt:	100 x 100 mm
RMS-rangert strøm/utgangseffekt:	4 W
Skjermlysstyrke (typisk):	250 cd/m²
Størrelseforhold:	16:9
Display:	LED
Innebygd TV-mottaker:	Nei
Kabellåsport:	Ja
Vippjustering:	Ja
Bildestørrelse, horisontal:	520.7 mm
Bildestørrelse, vertikal:	292.1 mm
Bildestørrelse, diagonal:	599.44 mm
Kabellåstype:	Kensington
Brukerguide på CD-ROM:	Ja
Lydkontakter:	Ja
AC-adapter bunt:	Ja
Støttede Mac operativsystemer:	Ja
