Side 1/27

TD2420

LCD Display

User Guide

Model No. VS15153

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Compliance Information

NOTE: This section addresses all connected requirements and statements regarding

regulations. Confirmed corresponding applications shall refer to nameplate labels

and relevant markings on unit.

FCC Compliance Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy, and if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modifications not expressly approved

by the party responsible for compliance could void your authority to operate the

equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du

Canada.

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage

Directive 2006/95/EC.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and

Electronic Equipment Directive 2002/96/EC (WEEE).The mark indicates

the requirement NOT to dispose the equipment as unsorted municipal

waste, but use the return and collection systems according to local law.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	TD2420
Energieffektivitetsklasse (gammel):	B
Type baklys:	W-LED
Berøringsskjerm:	Ja
Synsvinkel, horisontal:	170 °
Skjermform:	Flat
Pakkevekt:	3700 g
Antall HDMI-porter:	1
DVI-port:	Ja
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Hodetelefonutganger:	1
Sertifisering:	EPEAT Silver
HDCP:	Ja
3D:	Nei
HDMI:	Ja
Skjermteknologi:	LED
Digital horisontal frekvens:	24 - 83 kHz
Digital vertikal frekvens:	50 - 75 Hz
Kontrastforhold (dynamisk):	20000000:1
Vekt (med stativ):	3000 g
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
On Screen Display (OSD):	Ja
Kontrastforhold:	1000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Produktfarge:	Sort
Vippevinkelområde:	-5 - 20 °
Bredde (uten stativ):	555.9 mm
Høyde (uten stativ):	346.8 mm
Vekt (uten stativ):	2400 g
Bredde (med stativ):	555.9 mm
Dybde (med stativ):	174.8 mm
Høyde (med stativ):	421.9 mm
Skjermdiagonal:	23.6 "
LED-baklys:	Ja
Berøringsskjermtype:	Kiosk
Separat H/V-synkronisering:	Ja
Antall DVI-D-porter:	1
Kabler inkludert:	AC, Audio (3.5mm), DVI, USB, VGA
Strømforbruk (vanlig bruk):	25 W
Antall VGA (D-Sub)-porter:	1
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	ENERGY STAR
Dybde (uten stativ):	56.1 mm
Synsvinkel, vertikal:	160 °
Kan monteres på vegg:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 90
Lysstyrke for skjerm:	200 cd/m²
Oppdateringsresponstid:	5 ms
Panelmonterbart grensesnitt:	100 x 100 mm
RMS-rangert strøm/utgangseffekt:	4 W
Størrelseforhold:	16:9
Bildestørrelse, diagonal:	599.44 mm
Lydkontakter:	1
Synlig skjermområde (HxB):	520.69 x 292.09 mm
Strømforbruk, strømsparing:	20 W
Pakningsstørrelse (BxDxH):	506 x 151 x 498 mm
Dimensjoner (B x D x H) med stativ:	555.9 x 174.8 x 421.9 mm
