Side 1/96

V350

User Guide

Model No. VS14032

Compliance Information

CE SAR Information

THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO RADIO WAVES.

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the

limits for exposure to radio waves recommended by international guidelines. These

guidelines were developed by the independent scientific organization ICNIRP and

include safety margins designed to assure the protection of all persons, regardless of

age and health.

The exposure guidelines for mobile devices employ a unit of measurement known as

the Specific Absorption Rate or SAR. The SAR limit stated in the ICNIRP guidelines is

2.0 W/kg averaged over 10 grams of tissue. The actual SAR level of an operating

device can be below the maximum value because the device is designed to use only

the power required to reach the network. That amount changes depending on a

number of factors such as how close you are to a network base station. The highest

SAR value under the ICNIRP guidelines for use of the device at the body is 0.525 W/

kg and at the ear is 0.761 W/kg. Use of device accessories and enhancements may

result in different SAR values. SAR values may vary depending on national reporting

and testing requirements and the network band.

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage

Directive 2006/95/EC, R&TTE Directive 1999/5/EC.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and

Electronic Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as

unsorted municipal waste, but use the return and collection systems according

to local law.

If the batteries, accumulators and button cells included with this equipment,

display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a

heavy metal content of more than 0.0005% Mercury, or more than 0.002%

Cadmium, or more than 0.004% Lead.

European Union Regulatory Conformance

The equipment complies with the RF Exposure Requirement 1999/519/EC, Council

Recommendation of 12 July 1999 on the limitation of exposure of the general public to

electromagnetic fields (0–300 GHz). This equipment meets the following conformance

standards: EN62209-1/2, EN60950-1, IEC60950-1, EN50332-1/2, EN301489-1,

EN301489-3, EN301489-7, EN301489-17, EN301489-24, EN301511, EN301908-1/2,

EN300328, EN300440-1/2, EN55022, EN55024.

For the device which is tested in accordance to EN60950-1:2006, it is

mandatory to perform audio tests for EN50332. The device has been tested

to comply with the Sound Pressure Level requirement laid down in the

applicable EN 50332-1 and EN 50332-2 standards. Permanent hearing

loss may occur if earphones or headphones are used at high volume for prolonged

periods of time.

A pleine puissance, l’écoute prolongée du baladeur peut endommager l’oreille de

l’utilisateur.

The conformity assessment procedure has been followed with the involvement of the

following Notified Body:

PHOENIX TESTLAB

Identification mark: CE0700 (Notified Body) CE

We, hereby, declare that this cellular, Wi-Fi, & Bluetooth radio is in compliance with

the essential requirements and other relevant provisions of Directive 1999/5/EC.

Products with 2.4-GHz Wireless LAN Devices France

For 2.4-GHz wireless LAN operation of this product, certain restrictions apply. This

equipment may use the entire-2400-MHz to 2483.5-MHz frequency band (channels 1

through 13) for indoor applications. For outdoor use, only 2400-2454 MHz frequency

band (channels 1-9) may be used. For the latest requirements, see http://www.art-

telecom.fr.

This equipment may be operated in:

AT BE BG CH CY CZ DE DK

EE ES FI FR GB GR HU IE

IT IS LI LT LU LV MT NL

NO PL PT RO SE SI SK TR

0700

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Mobiltelefon
Modell:	V350
Vekt:	125 g
Bredde:	60.9 mm
Dybde:	12.45 mm
Høyde:	114 mm
Batterikapasitet:	1500 mAh
Bluetooth:	Ja
Berøringsskjerm:	Ja
Prosessorfrekvens:	0.6 GHz
Prosessorfamilie:	Qualcomm
RAM-kapasitet:	0.5 GB
2G-standarder:	EDGE, GPRS, GSM
3G-standarder:	HSDPA
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth-versjon:	2.1+EDR
GPS:	Ja
Videoopptak:	Ja
Type bakkamera:	Enkeltkamera
Plattform:	Android
Chat:	Ja
Antall USB 2.0-porter:	1
FM-radio:	Nei
Innebygd kamera:	Ja
Datanettverk:	3G
ROM-kapasitet:	512 MB
Batteriteknologi:	Lithium-Ion (Li-Ion)
Skjermoppløsning:	480 x 320 piksler
Støttede bildeformater:	BMP, GIF, JPEG XR, PNG
Støttede lydformater:	AAC
Produktfarge:	Sort
Skjermdiagonal:	3.5 "
Berøringsteknologi:	Multi-touch
Operativsystemprogramvare 04:	Android 2.2
Formfaktor:	Bar/Sperre
Paneltype:	TFT
Samtale venter:	Ja
Høyttalertelefon:	Ja
App-distribusjonsplattform:	Google Play
Maksimal størrelse på hukommelseskort:	32 GB
Videoformat som støttes:	H.263, H.264, MPEG4
Auto-fokus:	Ja
Bakkameraoppløsning (numerisk):	5 MP
SIM-kort kapasitet:	Dobbel SIM
MMS/bildemeldinger:	Ja
2G-bånd (primær SIM):	850,900,1800,1900 MHz
Samtale på vent:	Ja
E-mail:	Ja
Tekstmeldinger (SMS):	Ja
3G-båndet støttes:	900,2100 MHz
Mobilnettverksgenerasjon:	3G
Assisted GPS (A-GPS):	Ja
Instant Messaging (IM):	Ja
Minnekortstørrelse som medfølger:	2 GB
Auto-oppringing:	Ja
Viderekoble samtale:	Ja
Konferansesamtaler:	Ja
Tekstforutsigelse-systemtype:	T9
Tekstforutsigelsessystem:	Ja
Samtaleblokkering:	Ja
