For more product information, visit us at www.viewsoniceorope.com

3D gaming with ViewSonic

This ViewSonic 3D Monitors offers a pure, revolutionary 120Hz

frame rate combined with ultra-fast 2ms video response;a

technology partnership dedicated to delivering a truly immersive,

ultimate gaming experience just for you.

Full HD 1080p performance for unsurpassed HD viewing

Impressive 20,000,000:1 dynamic contrast ratio provides greater

detail and definition

Provides darker black levels and better overall front-of-screen

performance.

High brightness to reflect the true colour

300 nits high brightness delivers precise accurate colour to

realistically display a full array of brilliant shades and hues.

Eco-mode automatically reduces power consumption and can

extend backlight life and reduce operating power consumption

by up to 40%

SRS Premium Sounds

The two watt built-in audio speakers provide superior audio

quality for all multimedia applications while reducing desktop

space required by separate speakers.

Windows

7 certified

LCD

INPUT

COMPATIBILITY

CONNECTOR

SPEAKER

POWER

CONTROLS

OPERATING CONDITIONS

DIMENSIONS (WxHxD)

WEIGHT

REGULATIONS

WALL MOUNT (mm)

Size

Optimum Resolution

Brightness (cd/m²)

Contrast Ratio (typical)

Dynamic Contrast Ratio

Viewing Angle (CR

≧10)

Response Time (ms)

Pixel Pitch (H×V)

Panel Surface

Colour Support

Analogue

Sync

Frequency (Fh / Fv)

Mac

Analogue

Digital

Power

Audio

USB

Speaker

Voltage

Consumption (W)

Save mode (W)

Basic

OnView / OSD

Temperature

Humidity (Non condensed)

Physical (w/ stand)

Net (w/ stand)

VESA

Mount Complliant

60CM/23.6”wide Colour Active Matrix TFT LCD with 16:9 aspect ratio

1920×1080

300 (typical)

1000:1

20,000,000:1

170° (H), 160° (V)

5 (typical) / 2ms (G to G)

0.2715 mm (H) x 0.2715mm (V)

Anti-Glare, Hard coating (3H)

16.7 Millions

RGB Analogue (75 ohms, 0.7 / 1.0 Vp-p)

Separate Sync / Composite Sync / SOG

24–83kHz / 50–76Hz

VGA up to 1920×1080 Non Interlaced

1920×1080 Non Interlaced

1×15 pin mini D-sub

DVI-D / HDMI

Internal Power Adapter, 3-pin plug (CEE22)

1x3.5mm jack in/out

USB type-B for 3Dglasses

2w x 2 (SRS Premium Sounds)

AC 100-240V (Universal); 50/60Hz(Switch)

35 W (typical) w/o Audio / 38 W (maximum) with Audio

≦1W

[1], [2], Power, Down[▼], Up[▲]

Auto Image Adjust Contrast/Brightness, Input Select, D-SUB, DVI, HDMI PC, HDMI AV,

Audio Adjust, Volume, mute, Audio input, Colour AdjustsRGB, 9300K, 7500K, 6500K,

5000K, User Colour [R, G,B], Information Manual Image Adjust, H/V Position, Horizontal

Size, Fine Tune, Sharpness,Dynamic Contrast, Response Time, Aspect Ratio, Display

Mode, ECO Mode, Setup Menu, Language, Resolution Notice, OSD Position,

OSDTimeout, OSD Background, Auto Power Off, Sleep, Memory Recall

0 - 40 (°C) / 32 - 104 (°F)

10 - 90 (%)

563.6 mm (W) x417.7 mm (H)x260.8 mm (D)

5.1 Kg

BSMI, CCC, PSB, C-Tick, CE, Ergo, Gost-R/Hygienic, Ukraine, FCC-B, ICES-B, WEEE,

RoHS, Energy star 5.0, TCO 5.0

100 × 100

V3D241wm-LED

Get Ready to be Amazed

WW First 3D-LED DISPLAY

Model Name

V3D241wm-LED

Model No. VS13189

VSE 2010/08/11 V1

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	V3D241WM-LED
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	170 °
Antall HDMI-porter:	1
Hodetelefonutganger:	1
Sertifisering:	BSMI, CCC, PSB, C-Tick, CE, Ergo, FCC-B, ICES-B, WEEE, RoHS, TCO 5.0
Kontrastforhold (dynamisk):	20000000:1
Innebygd kamera:	Nei
Antall USB Type-A nedstrømsporter:	1
Kontrastforhold:	1000:1
Skjermoppløsning:	1920 x 1080 piksler
Produktfarge:	Sort
HD-type:	Full HD
USB-hub-versjon:	2.0
Bredde (uten stativ):	563.6 mm
Høyde (uten stativ):	417.7 mm
Vekt (uten stativ):	5100 g
Skjermdiagonal:	23.6 "
Naturlig sideforhold:	16:9
Hodetelefontilkobling:	3,5 mm
Antall DVI-D-porter:	1
Horisontalt frekvensområde:	24 - 83 kHz
Strømforbruk (vanlig bruk):	38 W
Antall VGA (D-Sub)-porter:	1
Strøminngang/AC (strøm) inn:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	ENERGY STAR
Dybde (uten stativ):	260.8 mm
Synsvinkel, vertikal:	160 °
Krav til strømforsyning:	AC 100-240V, 50/60Hz
Relativ luftfuktighet under drift (H-H):	10 - 90
Oppdateringsresponstid:	5 ms
Pikselbredde:	0.271 x 0.271 mm
Panelmonterbart grensesnitt:	100 x 100 mm
RMS-rangert strøm/utgangseffekt:	4 W
Skjermlysstyrke (typisk):	300 cd/m²
Størrelseforhold:	16:9
Innebygd TV-mottaker:	Nei
Kabellåsport:	Nei
Vertikal scanningsratio:	50 - 76 Hz
