Side 1/25

ViewSonic

VA2026w

LCD Display

Model No. : VS11802

ViewSonic VA2026w

Contents

TCO Information.......................................................................................... i

Compliance Information.............................................................................. 1

Important Safety Instructions...................................................................... 2

Declaration of RoHS Compliance............................................................... 3

Product Registration................................................................................... 4

Getting Started

Package Contents ...................................................................................... 5

Precautions ................................................................................................ 5

Quick Installation ........................................................................................ 6

Wall Mounting (Optional) ............................................................................ 7

Using the LCD Display

Setting the Timing Mode............................................................................. 8

OSD and Power Lock Settings ................................................................... 8

Adjusting the Screen Image ....................................................................... 9

Main Menu Controls ................................................................................. 11

Other Information

Specifications ........................................................................................... 14

Troubleshooting........................................................................................ 15

Customer Support .................................................................................... 16

Cleaning the LCD Display ........................................................................ 17

Limited Warranty ...................................................................................... 18

Mexico Limited Warranty .......................................................................... 20

ViewSonic VA2026w i

TCO Information

Congratulations!

The display you have just purchased carries the TCO’03 Displays

label. This means that your display is designed, manufactured and

tested according to some of the strictest quality and environmental

requirements in the world. This makes for a high performance

product, designed with the user in focus that also minimizes the

impact on our natural environment.

Some of the features of the TCO’03 Display requirements:

Ergonomics

Good visual ergonomics and image quality in order to improve the working environment for

the user and to reduce sight and strain problems. Important parameters are luminance, contrast,

resolution, reflectance, colour rendition and image stability.

Energy

• Energy-saving mode after a certain time - beneficial both for the user and the environment

• Electrical safety

Emissions

• Electromagnetic fields

• Noise emissions

Ecology

• The product must be prepared for recycling and the manufacturer must have a certified

environmental management system such as EMAS or ISO 14000

• Restrictions on

a. chlorinated and brominated flame retardants and polymers

b. heavy metals such as cadmium, mercury and lead.

The requirements included in this label have been developed by TCO Development in co-

operation with scientists, experts, users as well as manufacturers all over the world. Since the

end of the 1980s TCO has been involved in influencing the development of IT equipment in a

more user-friendly direction. Our labelling system started with displays in 1992 and is now

requested by users and IT-manufacturers all over the world.

For more information, please visit

www.tcodevelopment.com

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VA2026W
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	170 °
DVI-port:	Ja
Innebygde høyttalere:	Nei
Sertifisering:	UL, CUL, FCC-B (ICES), CB, CE, TCO'03, ICES-003B, ISO13406-2, TUV/GS, TUV ERGO (covers ISO13406-2 & MPRII), TUV-S, VCCI, GOST-R, HYGIENIC (20 copies), ENERGY, Energy Star, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS
3D:	Nei
Skjermteknologi:	LCD
Kontrastforhold (dynamisk):	2000:1
Innebygd kamera:	Nei
Vekt (med stativ):	4900 g
Tynn klient installert:	Nei
Kontrastforhold:	1000:1
AC-inngangsspenning:	90 - 264 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1680 x 1050 piksler
Strømforbruk (standby):	- W
Skjermoverflate:	Matt
Høydejustering:	Nei
Produktfarge:	Sort, sølv
Vippevinkelområde:	-5 - 20 °
Bredde (uten stativ):	- mm
Høyde (uten stativ):	- mm
Vekt (uten stativ):	- g
Bredde (med stativ):	510 mm
Dybde (med stativ):	225 mm
Høyde (med stativ):	432 mm
Skjermdiagonal:	20 "
Naturlig sideforhold:	16:10
Støttede grafikkoppløsninger:	1680 x 1050 (WSXGA+)
Kabler inkludert:	AC, DVI
Horisontalt frekvensområde:	24 - 82 kHz
Strømforbruk (vanlig bruk):	38 W
Antall VGA (D-Sub)-porter:	1
Strøminngang/AC (strøm) inn:	Ja
Driftstemperatur (T-T):	0 - 40 °C
VESA-montering:	Ja
Dybde (uten stativ):	- mm
Paneltype:	TFT
Synsvinkel, vertikal:	160 °
Av/på-bryter:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
Oppdateringsresponstid:	5 ms
Pikselbredde:	0.282 x 0.282 mm
Panelmonterbart grensesnitt:	100 x 100 mm
Skjermlysstyrke (typisk):	300 cd/m²
Størrelseforhold:	16:10
Display:	LCD
Innebygd TV-mottaker:	Nei
Kabellåsport:	Nei
Vippjustering:	Ja
Vertikal scanningsratio:	50 - 75 Hz
Plugg inn og spill:	Ja
