Side 1/60

VA2403/VA2403-h/

VA2403-mh/VA2403-mhv

Display

User Guide

Model No. VS17471

P/N: VA2403/VA2403-H/VA2403-MH/VA2403-MHV

IMPORTANT: Please read this User Guide to obtain important information on

installing and using your product in a safe manner, as well as registering your

product for future service. Warranty information contained in this User Guide will

describe your limited coverage from ViewSonic Corporation, which is also found on

our web site at http://www.viewsonic.com in English, or in specic languages using

the Regional selection box in the upper right corner of our website. “Antes de operar

su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic

As a world leading provider of visual solutions, ViewSonic is dedicated

to exceeding the world’s expectations for technological evolution,

innovation, and simplicity. At ViewSonic, we believe that our products

have the potential to make a positive impact in the world, and we are

confident that the ViewSonic product you have chosen will serve you

well.

Once again, thank you for choosing ViewSonic !

iii

Contents

1. Cautions and Warnings ..................................... 1

2. Getting Started ................................................... 4

2-1. Package Contents ............................................................. 5

2-2. The Exterior of the Monitor ................................................ 6

2-3. Hardware Installation ........................................................ 7

2-4. Quick Installation ............................................................. 11

2-5. Power On ........................................................................ 15

2-6. Driver Installation (Windows 10 Setup) ........................... 15

3. Adjusting the Screen Image ............................ 17

3-1. Setting the Timing Mode ................................................. 17

3-2. Adjusting the Screen Image ............................................ 18

4. OSD Menu Introduction ................................... 20

4-1. OSD Menu Tree .............................................................. 20

4-2. OSD Menu Explanation ................................................... 23

5. Specifications ................................................... 28

6. Troubleshooting ............................................... 30

7. Cleaning and Maintenance .............................. 31

Safe Cleaning Practices ......................................................... 31

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VA2403
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Pakkevekt:	4500 g
DVI-port:	Ja
Sertifisering:	CE, CB, ErP (with EEI label), WEEE, EAC, UkrSEPRO, TCO 7.0, BSMI
Skjermteknologi:	LCD
Kontrastforhold (dynamisk):	50000000:1
Vekt (med stativ):	3200 g
Kompatibilitet:	Windows 7, Windows 8, Windows 8.1, Windows 10 certified
Kontrastforhold:	3000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Produktfarge:	Sort
HD-type:	Full HD
Vippevinkelområde:	-5 - 22 °
Bredde (uten stativ):	544 mm
Høyde (uten stativ):	328 mm
Vekt (uten stativ):	2900 g
Bredde (med stativ):	544 mm
Dybde (med stativ):	199 mm
Høyde (med stativ):	407 mm
Pakkedybde:	121 mm
Pakkehøyde:	430 mm
Pakkebredde:	614 mm
Skjermdiagonal:	24 "
Naturlig sideforhold:	16:9
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Kabler inkludert:	AC, VGA
Strømforbruk (vanlig bruk):	22 W
Antall VGA (D-Sub)-porter:	1
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	REACH, RoHS, ENERGY STAR
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	49 mm
Paneltype:	TFT
Synsvinkel, vertikal:	178 °
Antall DVI-I-porter:	1
Relativ luftfuktighet under drift (H-H):	20 - 90
Oppdateringsresponstid:	5 ms
Pikselbredde:	0.272 x 0.272 mm
Panelmonterbart grensesnitt:	75 x 75 mm
Markedsplassering:	Hjem
Skjermlysstyrke (typisk):	250 cd/m²
Vippjustering:	Ja
Kompatibel med Mac:	Ja
