Side 1/2

VB-STND-003

Motorized Trolley Cart

Quick Setup Guide

Guide rapide début

Guía de configuración rápida

Konfigurationskurzanleitung

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

Industry Canada Statement

CAN ICES-3 (B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the relevant section of the EMC Directive 2014/30/EU, Low Voltage Directive

2014/35/EC, Eco-Design Directive 2009/125/EC, RoHS Directive (RED) 2011/65/EU

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive

2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted

municipal waste, but use the return and collection system according to local law.

CAUTION

This Cart for use only with specific ViewSonic Commercial Touch

Display.

See apparatus instructions. Use with other models is capable of

resulting in instability causing possible injury.

TIPPING HAZARD!

DO NOT move Cart with Display in highest position. DO NOT push

Cart from front or back of Lift. DO NOT move Cart over cords or

uneven, dirty, soft or sloping surfaces. DO NOT move Cart by

pushing on Display. Failure to comply with this caution may result in

Cart instability leading to equipment damage or personal injury.

Max.weight loading is 100kg

1.Duty cycle : please take rest for 18minutes for every

2 minutes continuous operation of the lift/ tilt

mechanism.

2.Please have the panel to the lowestposition while

moving the trolley.

Physical Dimensions

中国

http://www.viewsonic.com.cn

电话：4008 988 588

香港

http://www.hk.viewsonic.com

電話：852 3102 2900

澳門

http://www.hk.viewsonic.com

電話：853 2870 0303

台灣

http://www.viewsonic.com.tw

電話：0800 061 198

한국

http://ap.viewsonic.com/kr/

Phone: 080 333 2131

Europe

http://www.viewsoniceurope.co

Australia/New Zealand

http://www.viewsonic.com.au

Phone: 1800 880 818 (AUS)

0800 008 822 (NZ)

South Africa

http://ap.viewsonic.com/za/

Latin America

Chile/Mexico/Peru/Argentina

http://www.viewsonic.com/la/

http://www.viewsonic.com/

la/soporte/servicio-tecnico

Singapore/Malaysia/Thailand

http://www.viewsonic.com.sg

Phone: 65 6461 6044

India

http://www.in.viewsonic.com

Phone: 1800 266 0101

United States

http://www.viewsonic.com

Phone: 1-800-688-6688

(Toll-Free)

1-424-233-2530 (Toll)

Canada

http://www.viewsonic.com

Phone: 1-866-463-4775

(Toll-Free)

1-424-233-2533 (Toll)

Puerto Rico & Virgin Islands

http://www.viewsonic.com

Phone: 1-800-688-6688

(English)

http://www.viewsonic.com/

la/soporte/servicio-tecnico

(Español)

Specifications

Model VB-STND-003

Model No.

VS17474

Tilt

0° ~ 90°

Swivel

360 °

Height adjust range

490 mm

19.29 in

Wall mount pa ern 

800x600mm max.

Loading 75” max.

100 kg max.

220.46 lb max.

Input voltage

AC-in 100~240V 50/60Hz,1.0A

Control Physical bu on control, control pad, so ware icon  

Physical dimensions

1234 x 1149.6

x 844 mm

48.58 x 45.26 x 33.23 in

Net weight

54 kg

119.05 lb

Opera on Condi ons  

Temperature: 32°F to 104°F (0°C to 40°C)

Humidity: 20% ~ 80% non-condensing

Al tude: 

≦

2000M

Storage Condi ons Temperature: -4°F to 140°F (-20°C to 60°C) 

Humidity: 10% ~ 90% non-condensing

Al tude: 2000M ≦

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Ikke kategorisert
Modell:	VB-STND-003
Vekt:	54000 g
Bredde:	Blablabla mm
Dybde:	844 mm
Høyde:	1149.6 mm
Bruksanvisning:	Ja
Pakkevekt:	64000 g
Sertifisering:	FCC, cTUVus, CB, CE, RCM
Antall hjul:	4 hjul
Antall skjermer som støttes:	1
AC-inngangsfrekvens:	50/61 Hz
Maksimal skjermstørrelse:	75 "
Hjul:	Ja
Minimum skjermstørrelse:	55 "
Høydejusteringsområde:	0 - 560 mm
Motorisert:	Ja
Høydejustering:	Ja
Produktfarge:	Sort
Vippevinkelområde:	0 - 90 °
Pakkedybde:	934 mm
Pakkehøyde:	372 mm
Pakkebredde:	1342 mm
Kabler inkludert:	AC, USB
Harmonisert system (HS)-kode:	85299097
Modell/Type:	Bærbart gulvstativ
Kroppsmateriale:	Aluminium, Plastic, Steel
Vippjustering:	Ja
Dreietapp/dreiemekanisme:	0 - 360 °
AC-adapter bunt:	Ja
Montasjetype:	Gulv
Maksimalvekt (kapasitet):	100 kg
Monteringsgrensesnitt, kompatibilitet (min):	- mm
Monteringsgrensesnitt, kompatibilitet (maks):	800 x 600 mm
Antall inkluderte hyller:	1
