Side 1/4

VB-STND-004

Motorized Fixed Cart

Quick Setup Guide

Guide rapide début

Guía de configuración rápida

Konfigurationskurzanleitung

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

Industry Canada Statement

CAN ICES-3 (B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the relevant section of the EMC Directive 2014/30/EU, Low Voltage Directive

2014/35/EC, Eco-Design Directive 2009/125/EC, RoHS Directive (RED) 2011/65/EU

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive

2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted

municipal waste, but use the return and collection system according to local law.

CAUTION

This Cart for use only with specific ViewSonic Commercial Touch

Display.

See apparatus instructions. Use with other models is capable of

resulting in instability causing possible injury.

Max.weight loading is 100kg

Duty cycle : please take rest for 18minutes for every

2 minutes continuous operation of the lift/ tilt mechanism.

Physical Dimensions

Max.

16"(406mm)

Min.

2"(51mm)

Min.

4"(102mm)

2.5"(64mm)

7/32"

(5.5mm)

658mm

392mm

377mm

21mm

314mm

960mm

32mm

Min.

8"(203mm)

658mm

2.5"(64mm)

3/8"

(10mm)

2 3

77.5mm

220mm

320mm

10mm

60mm

220mm77.5mm

5 7

8 10

12 14

2 7

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Ikke kategorisert
Modell:	VB-STND-004
Vekt:	44300 g
Bredde:	960 mm
Dybde:	377 mm
Høyde:	1182 mm
Bruksanvisning:	Ja
Pakkevekt:	53500 g
Sertifisering:	FCC, cTUVus, CE, CB, RCM
Antall per pakke:	1 stykker
Antall skjermer som støttes:	1
AC-inngangsfrekvens:	50/62 Hz
Maksimal skjermstørrelse:	86 "
Minimum skjermstørrelse:	55 "
Høydejusteringsområde:	0 - 560 mm
Motorisert:	Ja
Høydejustering:	Ja
Produktfarge:	Sort
Pakkedybde:	795 mm
Pakkehøyde:	305 mm
Pakkebredde:	1155 mm
Kabler inkludert:	USB
Harmonisert system (HS)-kode:	85299097
Modell/Type:	Fast gulvstativ
Kroppsmateriale:	Aluminium, Plastic, Steel
AC-adapter bunt:	Ja
Montasjetype:	Bord
Maksimalvekt (kapasitet):	100 kg
Monteringsgrensesnitt, kompatibilitet (min):	- mm
Monteringsgrensesnitt, kompatibilitet (maks):	800 x 600 mm
Kan justeres i høyden:	Elektrisk
Antall inkluderte hyller:	1
