Side 1/22

ViewSonic

VE510b/VE510s

LCD Display

ViewSonic VE510b/VE510s

Contents

TCO Information.......................................................................................... i

Compliance Information.............................................................................. 1

Important Safety Instructions...................................................................... 2

Product Registration................................................................................... 3

Getting Started

Package Contents ...................................................................................... 4

Precautions ................................................................................................ 4

Quick Installation ........................................................................................ 5

Wall Mounting (Optional) ............................................................................ 6

Using the LCD Display

Setting the Timing Mode............................................................................. 7

OSD and Power Lock Settings................................................................... 7

Adjusting the Screen Image ....................................................................... 8

Main Menu Controls ................................................................................. 10

Other Information

Specifications ........................................................................................... 13

Troubleshooting........................................................................................ 14

Customer Support .................................................................................... 15

Cleaning the LCD Display ........................................................................ 16

Limited Warranty ...................................................................................... 17

ViewSonic VE510b/VE510s i

TCO Information

Congratulations!

You have just purchased a TCO’99 approved and labelled product!

Your choice has provided you with a product developed for

professional use. Your purchase has also contributed to reducing the

burden on the environment and also to the further development of

environmentally adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established method for encouraging

the adaptation of goods and services to the environment. With the growing manufacture and

usage of electronic equipment throughout the world, there is a recognized concern for the

materials and substances used by electronic products with regards to their eventual recycling

and disposal. By proper selection of these materials and substances, the impact on the

environment can be minimized.

There are also other characteristics of a computer, such as energy consumption levels, that are

important from the viewpoints of both the work (internal) and natural (external) environments.

Electronic equipment in offices is often left running continuously, resulting in unnecessary

consumption of large amounts of energy and additional power generation. From the standpoint

of carbon dioxide emissions alone, it is vital to save energy.

What does labelling involve?

The product meets the requirements for the TCO’99 scheme which provides for international

and environmental labelling of personal computers and/or displays. The labelling scheme was

developed as a joint effort by the TCO (The Swedish Confederation of Professional

Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature Conservation)

and Statens Energimyndighet (The Swedish National Energy Administration).

Approval requirements cover a wide range of issues: ecology, ergonomics, emission of

electrical and magnetical fields, energy consumption and electrical safety.

Ecological criteria impose restrictions on the presence and use of heavy metals, brominated

and chlorinated flame retardants, and other substances. The product must be prepared for

recycling and the manufacturing site(s) shall be certified according to ISO14001 or EMAS

registered.

Energy requirements include a demand that the system unit and/or display, after a certain

period of inactivity, shall reduce its power consumption to a lower level in one or more stages.

The length of time to reactivate the system unit shall be reasonable for the user.

Labelled products must meet strict environmental demands, for example, in respect of the

reduction of electrical and magnetical fields as well as work load and visual ergonomics.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VE510b
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	120 °
DVI-port:	Nei
Innebygde høyttalere:	Nei
Sertifisering:	TCO’99, ISO13046-2 (Pixelfehlerklasse II), Energy®, TÜV/GS, MPRII, UL, c-UL, FCC-B, CB, CE, IC-B, EPA, NOM, VCCI, BSMI, PSB (S-Mark), C-Tick, GOST-R (PCT-BZ02), PCBC (B-mark), EMI/B, Green Mark
HDCP:	Nei
3D:	Nei
Skjermteknologi:	LCD
Innebygd kamera:	Nei
Tynn klient installert:	Nei
Kontrastforhold:	450:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1024 x 768 piksler
Strømforbruk (standby):	- W
Skjermoverflate:	Matt
Høydejustering:	Ja
Produktfarge:	Sort
Bredde (uten stativ):	343 mm
Høyde (uten stativ):	326 mm
Vekt (uten stativ):	3000 g
Skjermdiagonal:	15 "
Naturlig sideforhold:	4:3
Støttede grafikkoppløsninger:	1024 x 768 (XGA)
Horisontalt frekvensområde:	30 - 62 kHz
Strømforbruk (vanlig bruk):	32 W
Antall VGA (D-Sub)-porter:	1
Strøminngang/AC (strøm) inn:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Dybde (uten stativ):	169 mm
Paneltype:	TFT
Synsvinkel, vertikal:	100 °
Av/på-bryter:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
Oppdateringsresponstid:	16 ms
Panelmonterbart grensesnitt:	- mm
Skjermlysstyrke (typisk):	250 cd/m²
Display antall farger:	16.78 million farger
Størrelseforhold:	4:3
Display:	LCD
Innebygd TV-mottaker:	Nei
Kabellåsport:	Nei
Bildestørrelse, horisontal:	304 mm
Bildestørrelse, vertikal:	228 mm
Vertikal scanningsratio:	50 - 85 Hz
Strømforbruk, strømsparing:	1 W
Plugg inn og spill:	Ja
Intervall maksimal driftstemperatur (T-T):	0 - 40 °C
