Side 1/80

VP2468

Display

User Guide

Model No. VS16475

P/N: VP2468

IMPORTANT: Please read this User Guide to obtain important information on

installing and using your product in a safe manner, as well as registering your

product for future service. Warranty information contained in this User Guide will

describe your limited coverage from ViewSonic Corporation, which is also found on

our web site at http://www.viewsonic.com in English, or in specic languages using

the Regional selection box in the upper right corner of our website. “Antes de operar

su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic

As a world leading provider of visual solutions, ViewSonic is dedicated

to exceeding the world’s expectations for technological evolution,

innovation, and simplicity. At ViewSonic, we believe that our products

have the potential to make a positive impact in the world, and we are

confident that the ViewSonic product you have chosen will serve you

well.

Once again, thank you for choosing ViewSonic !

iii

Contents

1. Cautions and Warnings ..................................... 1

2. Getting Started ................................................... 4

2-1. Package Contents ............................................................. 5

2-2. The Exterior of the Monitor ................................................ 6

2-3. Hardware Installation ........................................................ 7

2-4. Quick Installation ............................................................. 14

2-5. Power On ........................................................................ 18

3. Adjusting the Screen Image ............................ 20

3-1. Using the Control Panel .................................................. 20

3-2. Monitor Optimization ....................................................... 24

3-3. Driver Installation (Windows 10 Setup) ........................... 24

3-4. Setting the Timing Mode ................................................. 26

3-5. Additional Software Installation (Optional) ...................... 27

3-6. Monitor Firmware Update (Optional) ............................... 28

3-7. Auto Pivot (Optional) ....................................................... 30

3-8. Colorbration (Optional) .................................................... 31

4. OSD Menu Introduction ................................... 32

4-1. OSD Menu Tree .............................................................. 32

4-2. OSD Menu Explanation ................................................... 41

4-3. Monitor Setting Management .......................................... 49

4-4. OSD and Power Lock Settings ........................................ 50

5. Specifications ................................................... 51

6. Troubleshooting ............................................... 53

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VP2468
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Antall HDMI-porter:	2
Lydutgang:	Ja
Skjermteknologi:	LED
Kontrastforhold (dynamisk):	20000000:1
Antall DisplayPorts:	1
Vekt (med stativ):	5650 g
Fargespekter:	72.57
Antall USB Type-A nedstrømsporter:	4
Innebygd USB-hub:	Ja
Antall oppstrømsporter:	1
Kontrastforhold:	1000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Høydejustering:	Ja
Produktfarge:	Sort
HD-type:	Full HD
Vippevinkelområde:	-5 - 21 °
USB-hub-versjon:	3.2 Gen 1 (3.1 Gen 1)
Bredde (uten stativ):	538.67 mm
Høyde (uten stativ):	311.2 mm
Vekt (uten stativ):	3190 g
Bredde (med stativ):	538.67 mm
Dybde (med stativ):	215 mm
Høyde (med stativ):	519.48 mm
Skjermdiagonal:	24 "
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Strømforbruk (vanlig bruk):	22 W
Driftstemperatur (T-T):	0 - 40 °C
VESA-montering:	Ja
Dybde (uten stativ):	48.08 mm
Paneltype:	IPS
Svingvinkel:	0 - 90 °
Synsvinkel, vertikal:	178 °
Antall Mini DisplayPorts:	1
Relativ luftfuktighet under drift (H-H):	20 - 90
Oppdateringsresponstid:	14 ms
Panelmonterbart grensesnitt:	100 x 100 mm
Markedsplassering:	Forretning
Skjermlysstyrke (typisk):	250 cd/m²
Display antall farger:	16.78 million farger
Display:	LCD
Kabellåsport:	Nei
Vippjustering:	Ja
Dreibar:	Ja
Dreietapp/dreiemekanisme:	- °
Omdreiningsakse/midtpunkt:	Ja
Strømforbruk, strømsparing:	17 W
Aktivt skjermområde (B x H):	527 x 296 mm
