Viewsonic VSD243 Bruksanvisning

Viewsonic skjerm VSD243

Les nedenfor 📖 manual på norsk for Viewsonic VSD243 (30 sider) i kategorien skjerm. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/30

VSD243

Smart Display

User Guide

Model No. VS16340

Thank you for choosing ViewSonic

With over 30 years as a world leading provider of visual solutions, ViewSonic

is dedicated to exceeding the world’s expectations for technological evolution,

innovation, and simplicity. At ViewSonic, we believe that our products have the

potential to make a positive impact in the world, and we are condent that the

ViewSonic product you have chosen will serve you well.

Once again, thank you for choosing ViewSonic !

Compliance Information

Please read before proceeding

• Use only the batteries and power adapter provided by the manufacturer. The use of

unauthorized accessories may void your warranty.

• Do not store your device in temperatures higher than 50°C (122°F).

• The operating temperature for this device is from 0°C (32°F) to 35°C (95°F).

CE Conformity for European Countries

The device complies with the relevant section of the Low Voltage Directive

2014/35/EC, Eco-Design Directive 2009/125/EC, RoHS Directive 2011/65/EU,

WEEE Directive 2012/19/EU, and Radio Equipment Directive 2014/53/EU

European Union Regulatory Conformance

The equipment complies with the RF Exposure Requirement 2014/53/EU, Council

Recommendation of 12 June 2014 on the limitation of exposure of the general public to

electromagnetic elds (0-300 GHz). This equipment meets the following conformance

standards: EN301489-1, EN301489-17, EN55022/24, EN60950-1, EN300328.

We, hereby, declare that this Wi-Fi & Bluetooth radio is in compliance with the essential

requirements and other relevant provisions of Directive 2014/53/EU.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and

Electronic Equipment Directive 2012/19/EU (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted

municipal waste, but use the return and collection systems according to local law.

If the batteries, accumulators and button cells included with this equipment,

display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a

heavy metal content of more than 0.0005% Mercury, or more than 0.002%

Cadmium, or more than 0.004% Lead.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VSD243
Bluetooth:	Ja
Berøringsskjerm:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth-versjon:	4.0
Synsvinkel, horisontal:	178 °
Skjermform:	Flat
Pakkevekt:	7600 g
Antall HDMI-porter:	2
Innebygde høyttalere:	Ja
Strømforbruk (maks.):	40 W
Hodetelefonutganger:	1
Sertifisering:	cTUVus, FCC-B, FCC-ID, CA IC
Innebygd mikrofon:	Ja
Internminne:	2048 MB
HDMI:	Ja
HDMI-versjon:	1.4
Skjermteknologi:	LED
Innebygd kamera:	Ja
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
Antall USB Type-A nedstrømsporter:	4
Antall oppstrømsporter:	1
Antall samtidige berøringspunkter:	10
Berøringsskjermteknologi:	Kapasitiv
Kontrastforhold:	3000:1
Produktdesign:	Interaktivt flatpanel
AC-inngangsspenning:	100 - 240 V
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	2 W
eMMC-kapasitet:	16 GB
Produktfarge:	Sort
HD-type:	Full HD
Bredde (uten stativ):	572.9 mm
Høyde (uten stativ):	351.8 mm
Vekt (uten stativ):	5600 g
Pakkedybde:	140 mm
Pakkehøyde:	435 mm
Pakkebredde:	643 mm
Internminnetype:	DDR3
Minnekortenhet:	SD
Skjermdiagonal:	23.6 "
Berøringsteknologi:	Multi-touch
Berøringsskjermtype:	Kiosk
Operativsystemprogramvare 04:	Android
Strømforbruk (vanlig bruk):	16 W
Driftstemperatur (T-T):	0 - 35 °C
Harmonisert system (HS)-kode:	85285210
VESA-montering:	Ja
Dybde (uten stativ):	47 mm
Paneltype:	IPS
Synsvinkel, vertikal:	178 °
Innebygd prosessor:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 90
Lysstyrke for skjerm:	250 cd/m²
Oppdateringsresponstid:	16 ms
RMS-rangert strøm/utgangseffekt:	5 W
Størrelseforhold:	16:9
Strømforbruk, av:	0.5 W
AC-adapter bunt:	Ja
Formål:	Universell
Operativsystem, versjon:	8.1
USB oppstrømsporttype:	USB Type-B
