Side 1/25

VX2460h-LED

LCD Display

User Guide

Model No. VS14441

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specific languages using the Regional selection

box in the upper right corner of our website. #Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual#

Contents

Compliance Information.............................................................................. 1

Important Safety Instructions...................................................................... 2

Declaration of RoHS Compliance............................................................... 3

Product Registration................................................................................... 4

Getting Started

Package Contents ...................................................................................... 5

Precautions ................................................................................................ 5

Quick Installation ........................................................................................ 6

Using the LCD Display

Setting the Timing Mode............................................................................. 7

OSD and Power Lock Settings................................................................... 7

Adjusting the Screen Image ....................................................................... 8

Main Menu Controls ................................................................................. 10

Other Information

Specifications ........................................................................................... 15

Troubleshooting........................................................................................ 16

Customer Support .................................................................................... 17

Cleaning the LCD Display ........................................................................ 18

Limited Warranty ...................................................................................... 19

Mexico Limited Warranty .......................................................................... 21

Compliance Information

For U.S.A.

This device complies with part 15 of FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modifications not expressly approved by the

party responsible for compliance could void your authority to operate the equipment.

For Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage

Directive 2006/95/EC.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and

Electronic Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted

municipal waste, but use the return and collection systems according to local law.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	skjerm
Modell:	VX2460h-led
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	170 °
Pakkevekt:	5300 g
Antall HDMI-porter:	2
Strømforbruk (maks.):	28 W
Sertifisering:	CE, CB, BSMI, PSB, SASO, C-tick, KC, UL/cUL, FCC-B (ICES003), TUV-S, NOM, GOST-R/ Hygienic, UkrSEPRO, Erp, CCC, China Energy, EPEAT Silver, WEEE, RoHS, SVHC list
HDCP:	Ja
3D:	Nei
HDMI:	Ja
Sammensatt synkronisering:	Ja
Kontrastforhold (dynamisk):	40000000:1
Innebygd kamera:	Nei
On Screen Display (OSD):	Ja
Tynn klient installert:	Nei
Kontrastforhold:	1000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Produktfarge:	Sort
HD-type:	Full HD
Bredde (uten stativ):	581 mm
Høyde (uten stativ):	447 mm
Vekt (uten stativ):	3500 g
Pakkedybde:	517 mm
Pakkehøyde:	115 mm
Pakkebredde:	641 mm
Skjermdiagonal:	24 "
Naturlig sideforhold:	16:9
Hodetelefontilkobling:	3,5 mm
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Separat H/V-synkronisering:	Ja
Kabler inkludert:	AC, HDMI, VGA
Horisontalt frekvensområde:	24 - 83 kHz
Strømforbruk (vanlig bruk):	23 W
Antall VGA (D-Sub)-porter:	1
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	ENERGY STAR
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Nei
Hurtigstartsguide:	Ja
Dybde (uten stativ):	194 mm
Synsvinkel, vertikal:	160 °
Støttede Windows operativsystemer:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 90
Oppdateringsresponstid:	2 ms
Pikselbredde:	0.2715 x 0.2715 mm
Panelmonterbart grensesnitt:	- mm
Skjermlysstyrke (typisk):	250 cd/m²
Størrelseforhold:	16:9
Display:	LED
Innebygd TV-mottaker:	Nei
Kabellåsport:	Ja
Vertikal scanningsratio:	50 - 76 Hz
Kabellåstype:	Kensington
Gjennomsnittstid mellom feil (MTBF):	40000 timer
Støttede Mac operativsystemer:	Ja
IC-inngang:	Nei
Vanlig grensesnitt pluss (CI+):	Nei
Sync-on-green (SOG):	Ja
