Side 1/4
• Ideal for areas where personal attention must be
given to every call
• Eliminates the additional cost of adding a PABX
console or key system
• Allows for full utilization of all call pickup
features
• Monitors the status of lines or stations
• Non-volatile memory (no batteries required)
• Visual status for up to 24 analog lines or
stations (idle, in-use, ringing)
• Programmable ring indication on a per-line
basis
• Adjustable display viewing angle for desk or
wall mounting
• Displays require only a single pair of wires
• Powers up to (3) LM-24D or LM-12W displays
• User printable extension identification cards
• Adjustable audio volume
• Quick installation
• Includes both the display and the scanner
• One year limited warranty
The LM-24S Line Status Monitor
System provides a visual status of up
to 24 lines or stations. If a line or
station is in use, the corresponding
LED will light steady, a ringing line or
station will show a flashing LED.
See at a Glance when Lines are Ringing
or In-Use
VIKING©
Technical Practice
Telecommunication Peripheral Products
LM-24S
Line Status Monitor
System
July 5, 2000
Features Applications
Sales...(715) 386 - 8861
Power: 120V AC/13.8V AC 1.25A UL listed adapter provided
Dimensions: LM-24M - 187mm x 127mm x 45mm (7.37” x 5” x
1.75”), LM-24D - 184mm x 119mm x 38mm (7.25” x 4.7” x 1.5”)
Shipping Weight: LM-24M - .68 Kg (1.5 lbs), LM-24D - .59 Kg
(1.3 lbs)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95% non-
condensing humidity
Connections: (1) RJ21X connector, (1) RJ11 jack
Maximum Display Runs: (1) display: 244m (500 ft), (2) display:
122m (400 ft), (3) displays: 61m (200 ft)
Specifications
http://www.VikingElectronics.com
E-mail...Sales@VikingElectronics.com
Even if a ringing phone is out of
hearing range, a common audible
tone calls the operator’s attention to
the visible display. The tone is
adjustable for convenient operation.
The LM-24S Line Status Monitor System is designed for professional and efficient call
processing at department answering positions, message centers and back-up
attendant stations. Each LM-24S Line Status Monitor System includes one LM-24D
Display and one LM-24M Scanner.
See at a Glance when
Lines are Ringing
or In-Use
LM-24M LM-24D
