Compact Color Camera Kits and
Single Gang Mountable Cameras
The VCAM-1 and VCAM-1IR are high resolution color composite video cameras. Their compact
size will allow mounting in even the smallest locations. The extreme temperature rating of this cam-
era, makes it ideal for mounting in outdoor locations in a water tight enclosure.
The VCAM-2 is a compact, high resolution color composite video camera mounted behind a stan-
dard single gang wall plate. The VCAM-2 is available in two finishes: Brushed Stainless Steel
(VCAM-2-SS) and Oil Rubbed Bronze (VCAM-2-BN). The extreme temperature rating and
Enhanced Weather Protection make this camera ideal for mounting
in outdoor locations.
The VCAM-1 is not compatible with IR illuminators and is a direct
replacement for the cameras included in the following Viking models: AES-2005, E-35, E-50,
E-65, E-75, K-1205, K-1705-3 and W-3005.
The VCAM-1IR has a day/night OLP (optical low pass) filter and is compatible with standard
840-850nM IR illuminators. The VCAM-1IR is the same size as the VCAM-1 allowing it to be
used in all of the above Viking products.
All cameras are equipped with Enhanced Weather Protection (EWP) for outdoor installations
where the unit is exposed to precipitation or condensation. The VCAM-1, VCAM-1IR and
VCAM-2 feature sealed connections, as well as an epoxy potted circuit board.
F
F
e
e
a
a
t
t
u
u
r
r
e
e
s
s
P
P
h
h
o
o
n
n
e
e
.
.
.
.
.
.
7
7
1
1
5
5
.
.
3
3
8
8
6
6
.
.
8
8
8
8
6
6
1
1
Shipping Weight: VCAM-1 / VCAM-1-IR: 0.45 kg (1.0 lbs)
VCAM-2: 0.36 kg (0.8 lbs)
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Connections: (3) gel-filled butt connectors (3M Scotchlok UR2)
(See page 2 for complete specifications)
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
h
h
t
t
t
t
p
p
:
:
/
/
/
/
w
w
w
w
w
w
.
.
v
v
i
i
k
k
i
i
n
n
g
g
e
e
l
l
e
e
c
c
t
t
r
r
o
o
n
n
i
i
c
c
s
s
.
.
c
c
o
o
m
m
A
A
p
p
p
p
l
l
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
• Door entry
• Gate entry
• Covert surveillance
i
i
n
n
f
f
o
o
@
@
v
v
i
i
k
k
i
i
n
n
g
g
e
e
l
l
e
e
c
c
t
t
r
r
o
o
n
n
i
i
c
c
s
s
.
.
c
c
o
o
m
m
Model VCAM-1
and VCAM-1IR
Model VCAM-2
VCAM-1 / VCAM-1-IR / VCAM-2 Features:
• High resolution color composite video camera with wide 80° viewing
angle, tilt/swivel adjustments, and wide operating temperature range
• Designed for outdoor use, all cameras come standard with Enhanced
Weather Protection (EWP), see DOD# 859 for more information
• All cameras designed to meet IP66 Ingress Protection Rating
• 12V DC adapter and wire connectors included
• VCAM-1-IR only: IR illuminator compatible
VCAM-2 Features:
• Compact size: Front panel is the size of a typical single gang midsize
wall plate
• Mounting: Flush mount in a single gang electrical box (2.25” deep x
2.00” wide x 2.84” tall min) electrical box or surface mount in a Viking
model VE-3x5 (not included, see DOD# 424)
• Available in 2 standard faceplate finishes: Brushed Stainless Steel
and Oil Rubbed Bronze
• PNL-VCAM-2 faceplates: Replacement faceplates with matching
screws available in both finishes
• Vandal Resistant Features: 18 gauge 304 stainless steel faceplate,
stainless steel camera mounting plate, scratch resistant powder
coating, impact and scratch resistant camera lens, and hex drive
mounting screws
• Weather Resistant Features: Faceplate gasket, sealed camera lens,
potted camera circuit board, stainless steel camera mounting hardware
• VCAM-2-BN only: UV stable weather resistant powder coating
