Side 1/32
IMMERSI-PREP™ 14, 16, 18, 21, & 23 IMMERSIon BlEndER
U.S. Patent: vitamix.com/patents
VM0224, VM0242, VM0243, VM0244, VM0245, & VM0246
SymbolS
Warning and Caution On / O
NEVER touch moving parts. Keep hands and
utensils away from the blade assembly.
Electric Shock Hazard
High temperatures exist when blending hot
liquids.
Read and understand the owner’s manual.
Unplug while not in use, before cleaning, changing accessories, or touching parts that move.
Parts will become hot with extended use. NEVER touch the drive socket in the motor assembly or the
drive spline in the attachment connector.
VITA-MIX® CORPORATION
8615 Usher Road, Cleveland, Ohio 44138 U.S.A.
Tel (International): 1.440.782.2450
Technical Support: 1.800.886.5235
Email: commercialts@vitamix.com
SpecificationS
model
HeigHt
(motor witH wand)
appliance
witH wand
wand only
Voltage: 120 V Immersi-Prep 14: 31.6 inches / 80,3 cm 12.5 lbs / 5,7 kg 3.8 lbs / 1,7 kg
Frequency: 60 Hz Immersi-Prep 16: 33.6 inches / 85,3 cm 12.9 lbs / 5,9 kg 4.3 lbs / 1,9 kg
Current: 10.5 amps Immersi-Prep 18: 35.6 inches / 90,4 cm 13.2 lbs / 6,0 kg 4.5 lbs / 2,1 kg
Depth: 8.3 inches / 21,1 cm Immersi-Prep 21: 38.6 inches / 98,0 cm 13.8 lbs / 6,3 kg 5.1 lbs / 2,3 kg
Width: 5.8 inches / 14,7 cm Immersi-Prep 23: 40.6 inches / 103,1 cm 14.1 lbs / 6,4 kg 5.4 lbs / 2,4 kg
Important SafeguardS
151122
2
WARNING
Carefully read all instructions before operating the appliance for
the first time. Save these instructions for future reference.
ALWAYS use grounded outlets.
NEVER remove the ground.
NEVER use an adapter.
NEVER use an extension cord.
NEVER plug the appliance into a timer or an outlet controlled by a
switch.
ALWAYS turn o AND unplug the appliance when not in use and
before assembling, disassembling, moving, cleaning, and storing.
NEVER put the power cord, power plug, or immersion motor assembly
in water or otherliquid.
If the appliance becomes submerged, unplug immediately.
Failure to follow instructions can cause death or electrical shock.
This product is intended for COMMERCIAL USE ONLY and is not
intended to be used for household purposes.
1. THE FAILURE TO FOLLOW ANY OF THE IMPORTANT SAFEGUARDS AND
IMPORTANT INSTRUCTIONS FOR SAFE USE IS A MISUSE OF YOUR VITAMIX
BLENDER THAT CAN VOID YOUR WARRANTY AND CREATE THE RISK OF
SERIOUS INJURY.
2. The instructions appearing in this manual cannot cover every possible
condition and situation that may occur. Common sense and caution must be
practiced when operating and maintaining any appliance.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience or
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety and if they
understand the hazards involved.
4. NEVER let children use or play with the appliance. Keep the cord out of reach
from children.
5. Remove and discard packaging materials, the power plug cover, and
promotional labels before using the appliance for the first time.
6. NEVER unplug the appliance by pulling on the cord. To unplug the appliance,
grasp the power plug and pull from the outlet.
7. NEVER operate the appliance with loose, nicked, or damaged blending blades.
Check the blending blades daily and discontinue use if blades are damaged.
8. NEVER come in contact with moving parts, especially the blending blades.
9. NEVER tighten the acorn nut (on the top of the blending blades). If loose,
discontinue use of the appliance.
10. NEVER place the appliance on or near a hot gas or electric burner, or where
it could touch any other source of heat.
11. If the apppliance will not operate, unplug the appliance and reset the GFCI.
If the circuit breaker continues to trip, unplug the appliance from the outlet
and contact a qualified electrician.
12. NEVER allow the power cord to hang over the edge of a table or counter,
touch hot surfaces, or become knotted.
13. ALWAYS ensure the appliance is completely and properly assembled and the
power cord is fully unwound before use.
14. The blending blades are very sharp. Handle carefully and keep out of reach
of children.
15. ALWAYS ensure the appliance is unplugged from the power outlet before
attempting to assemble any of the attachments.
16. NEVER use attachments other than those provided with the appliance
or oered separately from Vitamix. The use of attachments not sold or
recommended by Vitamix may cause fire, electric shock or injury.
Important SafeguardS
3151122
17. Alteration or modification of any part of the appliance, including the use of any
part or parts that are not genuine authorized Vitamix parts, may cause fire,
electric shock, or injury and will void your warranty.
18. If using the appliance to blend hot food, keep hands and other exposed skin
away from the top of container or pot and use the lowest speed setting to
avoid burns from escaping steam or splashes.
19. Extreme caution must be used when moving a container filled with hot oil or
other hot liquids. Escaping steam or splashes may scald.
20. NEVER touch surfaces that may be hot.
21. If during use, the sound of the appliance changes or if a hard or foreign object
comes into contact with the blending blades, NEVER serve the food being
made with the appliance.
22. NEVER remove ingredients from the blending container during operation.
Ensure the motor has completely stopped and the appliance is unplugged
before removing any ingredients.
23. If food becomes lodged around the blending blades, release the On/O
Button, unplug the power cord, and remove the attachment from the motor
assembly. Use a spatula to dislodge the food. NEVER use fingers as the
blending blades are sharp.
24. Keep hands, hair, clothing, and utensils away from all moving parts during
operation to reduce the risk of severe injury to persons and/or damage to the
appliance. A spatula may be used, but only when the appliance is not running
and unplugged.
25. NEVER submerge the motor assembly and whisk gear housing in water or
place in the dishwasher.
26. NEVER leave the working area when the appliance is in use, including during
the use of Continuous Run mode.
27. When mixing liquids, especially hot liquids, use a tall container or make small
quantities at a time to reduce spillage.
28. If the blending wand detaches from motor assembly during use, unplug unit
immediately. If blending wand is detached and submerged in hot liquid, use
caution when removing. If problem persists, discontinue use and contact
Vitamix Commercial Technical Support at 800.886.5235.
29. NEVER leave any foreign object, such as spoons, forks, or knives, in the
container you are blending in as this will damage the blending blades and
other components when starting the blender and may cause injury.
30. If the blend is not processing when blending thick or heavy mixtures, stop
operation and stir the ingredients before continuing. Allow the motor to cool
for 1 minute before turning the appliance back on.
31. Strictly follow the care and cleaning instructions provided in this manual.
32. NEVER allow the blending blades to soak in water.
33. NEVER use the appliance for anything other than its intended use.
34. NEVER use outdoors or on moving vehicles or boats.
35. To turn the appliance o, release the On/O button. To turn the appliance o
when in Continuous Run mode, press any button and remove the plug from the
power outlet.
36. Use caution when blending in a container, pot, pan, and on the stove top.
37. NEVER lean on or support anything other than the motor assembly or blending
attachments on the wall mount bracket.
38. Regularly inspect the power cord, power plug, power cord GFCI, and the
appliance for any damage. NEVER operate if damaged in any way or after
the appliance malfunctions. Immediately cease use of the appliance and visit
vitamix.com or call Vitamix Commercial Technical Support at 1.800.886.5235
(International: 1.440.782.2450) for examination, repair, or adjustment.
39. Test the power cord GFCI before each use.
40. Any repair, servicing, or replacement of parts must be performed by Vitamix or
a Vitamix authorized service representative.
41. SAVE THESE INSTRUCTIONS.
