Vivotek ND9312 Bruksanvisning

Vivotek Videoopptaker ND9312

Les nedenfor 📖 manual på norsk for Vivotek ND9312 (180 sider) i kategorien Videoopptaker. Denne guiden var nyttig for 3 personer og ble vurdert med 4.9 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/180

VIVOTEK - Built with Reliability

User's Manual - 1

Rev. 1.6.1.11

Rev. 1.0

User’s Manual

ND9312

Network Video Recorder

H.265/H.264 • 8 CH • 1 HDD • ONVIF • Fisheye Dewarp •

HDMI Monitor Display • Auto Setup • Auto Adaptive Stream

Rev. 1.0

VIVOTEK - Built with Reliability

2 - User's Manual

Table of Contents

Chapter One Hardware Installation and Initial Conguration ...................................................................................... 7

Introducing the Network Video Recorder ............................................................................................................... 7

Special Features ............................................................................................................................................. 7

Safety .............................................................................................................................................................. 8

Chassis Dimensions .................................................................................................................................... 9

Screw Dimensions ...................................................................................................................................... 9

Physical Description ........................................................................................................................................... 10

Hardware Installation .......................................................................................................................................... 11

Interface Connections ......................................................................................................................................... 15

Initial Conguration - via a Web Console (Optional) ............................................................................................ 24

LED Indicators ...................................................................................................................................................... 27

Power Up and Power Down ................................................................................................................................. 28

Section One Management over a Local Console ...................................................................................................... 29

Chapter Two Introduction to the Local Console Interface .......................................................................................... 29

2-1. How to Begin .......................................................................................................................................... 31

2-2. Operation on Camera View Cell ............................................................................................................. 37

2-2-1. PTZ Panel ........................................................................................................................................... 37

2-2-2. Digital zoom Panel .............................................................................................................................. 41

2-2-3. Play Recording Clips Panel ................................................................................................................ 42

2-2-4. DI/DO .................................................................................................................................................. 43

2-2-5. Others ................................................................................................................................................. 43

2-2-6. Right-click Commands ........................................................................................................................ 44

Chapter Three Conguation Using the Local Console .............................................................................................. 45

The Main Control Portal ....................................................................................................................................... 45

3-1. Layout .................................................................................................................................................... 45

3-2. DI/DO ..................................................................................................................................................... 45

3-3. Search recording clips ........................................................................................................................... 46

3-3-1. Basic Search ................................................................................................................................ 46

3-3-2. Alarm Search ............................................................................................................................... 50

3-3-3. POS Search ................................................................................................................................. 53

3-3-4. Storyboard ................................................................................................................................... 56

3-4. Export recordings ................................................................................................................................... 60

3-5. Settings .................................................................................................................................................. 62

3-5-1. Settings - Overview ...................................................................................................................... 62

3-5-2. Settings–Camera–Management .................................................................................................. 63

3-5-3. Settings–Camera–Recording....................................................................................................... 70

3-5-4. Settings–Camera–Recording....................................................................................................... 71

3-5-5. Settings–Camera–Media ............................................................................................................. 73

3-5-6. Settings - Camera - Image ........................................................................................................... 80

3-5-7. Settings–Camera–Motion Detection ............................................................................................ 82

Produkspesifikasjoner

Merke:	Vivotek
Kategori:	Videoopptaker
Modell:	ND9312
Vekt:	530 g
Bredde:	198 mm
Dybde:	200 mm
Høyde:	47 mm
Maksimal oppløsning:	3840 x 2160 piksler
Antall USB 2.0-porter:	2
Strømforbruk (maks.):	15 W
Sertifisering:	CE, LVD, FCC, VCCI, C-Tick, UL
Internminne:	1024 MB
Støttede nettverksprotokoller:	IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter
PTZ-kontroll:	Ja
Støttet nettleser:	nternet Explorer 10 (32 bit) or later / WindowsChrome v68.0.3 & Firefox v61.02 or later / Windows & macOS
HDD-størrelse:	3.5 "
Maksimal lagringskapasitet:	- TB
Øyeblikksbilde:	Ja
HDMI-utgang:	Ja
Støttede bildeformater:	JPEG
Støttede lydformater:	G.711, G.726
Produktfarge:	Hvit
Operativsystemprogramvare 04:	Integrert LINUX
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Intern harddisk:	- GB
Innebygd prosessor:	Ja
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Relativ luftfuktighet under drift (H-H):	0 - 95
Videoformat som støttes:	H.264, H.265, M-JPEG
Videobasert bevegelsesdeteksjon:	Ja
Video inngang-kanaler:	8 kanaler
Lydkodekser:	G.711, G.726
Backup-funksjon:	Ja
Antall støttede HDDer:	1
Playback-modus:	Frame by Frame
Avspillings-kontroll:	Ja
Innspillingsmodus:	Continuous, Event, Manual, Schedule
Antall samtidige avspillings kanaler:	4 kanaler
