Side 1/29

FlexVent™ Versatile Slide-In

with Downdraft Vent System and

Fire Suppression

INSTALLATION MANUAL

Model FC-6DV | Installation Guide

FlexVent™ versatile slide-in

with downdraft vent system

and fire suppression

SAFETY INFORMATION

This manual provides information for safely conﬁguring, installing, operating, and maintaining FlexVent™. Always follow guid-

ance from the Authority Having Jurisdiction (AHJ) for regulation and code compliance.

DO NOT install or operate the unit until all safety information and instructions are thoroughly read and understood. Installation

and startup must be performed by a qualiﬁed technician. The warranty will be void if the unit is not installed correctly.

NOTE: This product is UL Recognized. UL Recognized components are incomplete in certain constructional features and

require professional installation and subsequent evaluation to relevant standards prior to commissioning.

For your safety, please observe the following precautions when installing, operating, or servicing FlexVent™.

WARNING indicates a potential hazard that can or will cause severe injury or death.

CAUTION indicates a potential hazard that can cause minor or major injury.

NOTE: indicates important information.

WARNING — HAZARDOUS VOLTAGE

• Failure to disconnect unit from electrical supply before any servicing could result in death, serious injury, or

equipment damage.

• Unit must be installed by qualiﬁed personnel in accordance with applicable codes and ordinances.

• Install and use Recognized electrical components and grounded electrical outlets matching each intended

cooking appliance’s nameplate rated voltage.

• Ensure breaker panel service, circuit breaker, and wiring is appropriate for all intended cooking appliances and

conﬁgurations.

• Do not steam clean, spray, or pour liquids on any part of the unit.

• Unit must be installed and secured level to the enclosure.

• Do not use extension cords for appliances.

• Before cleaning or maintenance, turn the unit o and disconnect the electrical supply.

• Always attend the unit when in operation.

• Do not operate the unit if damaged or malfunctioning.

WARNING — COMBUSTION & FIRE HAZARDS

• Do not attach ductwork to the Recirculating System exhaust; it is designed to prevent a ﬁre from spreading

outside of the unit.

• Ensure all ﬂammable substances and vapors are stored away from this unit and other appliances.

• Ceiling height must be at least 96”.

• Do not modify or in any way circumvent or defeat the Interlock Box as factory wired.

• Appliances and conﬁgurations must conform to Cooking Appliance Constraints noted in this manual.

• AHJ approvals are required for all potential appliances and conﬁgurations upon initial installation.

iii

Model FC-6DV | Installation Guide

WARNING

• Improper installation, adjustment, alteration, service or maintenance could result in serious injury, equip-

ment or property damage, and may void the factory warranty.

• This product may contain chemicals know to the state of California to cause cancer, birth defects, or

other reproductive harm. For more information go to www.p65warnings.ca.gov.

CAUTION

• Avoid impact to the Touch Panel surface; damage may cause unit malfunction.

• Filters should not be altered in any way; damaged ﬁlters must be replaced prior to operation.

• DO NOT clean with corrosive chemicals, products containing chlorine, oven cleaners, or abrasive

cloths or cleaners.

• DO NOT alter, add attachments or modify this unit unless speciﬁed in this manual.

• Ensure the enclosure provides adequate ventilation as speciﬁed in this manual.

NOTE — UNPACKING & INSTALLATION

• Ensure there is enough space to unpack; there will be layers of protective packaging.

• Use care when unpacking to prevent the unit from tipping and being damaged.

• Immediately inspect the unit and notify the freight company if damage is present.

• Remove crating materials, stretch wrap, and packaging. The unit is secured to the pallet; it is often help-

ful to leave the unit on the pallet to facilitate moving to its fabrication location.

• Fabricators and owners are responsible for installation materials not included with purchase.

• Move the unit with appropriate equipment and adequate people to avoid injuries and unit damage.

NOTE: If the unit is removed from the pallet, move using the four mounting pads provided under the

unit. Using other areas to lift will cause damage to the unit. DAMAGE RESULTING FROM IMPROPER

HANDLING WILL VOID THE WARRANTY.

• Remove and retain the envelope that contains included hardware, labels, and documentation.
