Operator’s Manual
Conveyor Toasters, 350-1000 Slices Per Hour
Models JT2, JT2H, JT3, JT3H
©
2017 The Vollrath Company L.L.C. Part No. 350774-1 en 9/6/17
Register your product at Vollrath.com/registration and become eligible to win a free 10" Vollrath Tribute® fry pan.
Thank you for purchasing this Vollrath equipment. Before operating the
equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. Save the original box and packaging. Use this packaging
to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment
• Plug only into grounded electrical outlets matching the voltage on
the rating plate.
• Use this equipment in a flat, level position.
• Unplug equipment and let it cool before cleaning or moving.
Equipment remains hot after it is turned off.
• Unplug when not in use.
• Keep equipment and power cord away from open flames, electric
burners or excessive heat.
• Do not operate unattended.
• Closely supervise equipment operating in public areas and/or
around children.
• Do not operate if equipment has been damaged or is malfunctioning.
FUNCTION AND PURPOSE
This equipment is intended to toast bread products. It is intended for
use in commercial foodservice operations only. It is not intended for
household, industrial or laboratory use.
CLEARANCE AND ENVIRONMENT REQUIREMENTS
Do not place toaster on surfaces or near walls, partitions or kitchen
furniture unless they are made of non-combustible material or clad with
non-combustible heat-insulating material. Toasters must not be used
near or below curtains and other combustible materials.
Do not place the toaster adjacent to a heat producing appliance.
SET UP
1. Place the toaster on a hard, flat, stable surface.
2. Turn the toaster on it’s side with the bottom facing you.
3. Install the feet.
NOTICE: Feet must be installed. Failure to install the feet will
restrict airflow and cause the toaster to overheat.
4. Install the collection pan by placing the back edge of the pan on the
lip at the back of the toaster. Line up the hole in the pan with the
screw. Tighten the screw to secure the collection pan.
WARNING
CAUTION
Item No. Model Description
CT4-120450
JT2
120V, 450 Slices Per Hour
CT4-208800 208V, 800 Slices Per Hour
CT4-220800 220V, 800 Slices Per Hour
CT4-240800 240V, 800 Slices Per Hour
CT4H-120300
JT2H
120V, 300 Slices Per Hour, High Clearance
CT4H-208550 208V, 550 Slices Per Hour, High Clearance
CT4H-220550 220V, 550 Slices Per Hour, High Clearance
CT4H-240550 240V, 550 Slices Per Hour, High Clearance
CT4-2081000
JT3
208V, 1000 Slices Per Hour
CT4-2201000 220V, 1000 Slices Per Hour
CT4-2401000 240V, 1000 Slices Per Hour
CT4H-208950
JT3H
208V, 950 Slices Per Hour, High Clearance
CT4H-220950 220V, 950 Slices Per Hour, High Clearance
CT4H-240950 224V, 950 Slices Per Hour, High Clearance
2 Conveyor Toasters, 350-1000 Slices Per Hour Operator’s Manual – Models JT2, JT2H, JT3, JT3H
BEFORE FIRST USE
1. Clean the toaster. See “Daily Cleaning” on page 3.
2. Insert the crumb tray. Make sure the feed ramp is placed in the up
position.
FEATURES
OPERATION
NOTICE: The crumb tray must be installed in the toaster during
operation. Failure to install the crumb tray will cause the
toaster to overheat.
Tips
Preheat
1. Plug the toaster into a grounded electrical outlet that matches the
rating on the name plate found on the side of the toaster.
NOTICE: Using a voltage other than the nameplate rated voltage
will cause damage to the unit. Incorrect voltage,
modification to the power cord or electrical components
can damage unit and will void the warranty.
2. Toasters with an adjustable heat shield: Adjust the heat shield so the
tallest bread product can pass below it. Excess space above the
product will create heat loss and may reduce performance.
3. Rotate the power knob to the full power position (I).
4. Set the conveyor speed control knob to 7.
5. Rotate the top and bottom heat control knobs to high.
6. Wait 5 minutes for the toaster to preheat.
Test
1. Adjust the settings for the product to be toasted. See the Tips chart
at the top of this page. Test the settings by placing a sample of the
bread items to be toasted onto the feed ramp. Place bagels or buns
onto the feed ramp with the cut side facing up.
For One-Sided Toasting, Set:
TOP heat control to the desired setting.
BOTTOM heat control to the OFF position.
2. Evaluate the results.
Toast
1. Adjust the top and bottom heat control settings and conveyor as
needed for even toasting on each side of the bread product. Allow
time for the toaster to adjust to new heat settings before placing
bread on the conveyor.
2. For best performance do not overload the toaster. Wait a few
seconds before loading a second row of bread into the toaster.
If a Bread Item Becomes Stuck
1. Rotate the power knob to the OFF position (O) and unplug the
toaster.
2. Let the toaster cool completely.
3. Use a tong to remove the bread item. Take care to not bump the
glass heating elements above and below the conveyor.
A Conveyor Speed Control Knob
B Power Knob
Full Power - maximum heat
Off
Standby - reduces electrical consumption by 75%.
C Heat Shield - Adjustable on the high-clearance toasters
D Feed Ramp
E Crumb Tray
F Top Heat Control Knob
G Bottom Heat Control Knob
H Collection Pan
I Reset Button (Reference only. Access is via the front of the
toasters. See page 3.)
C
D
E
F
G
H
A
B
I
Back View
CAUTION
Burn Hazard
Do not touch the equipment while it is heating or operating.
Hot surfaces can burn skin.
Bread Product Suggestions
Bagels, wheat or rye bread or
products with high moisture content.
Use a slower conveyor speed.
Buttered or coated, such as pastries Not recommended.
Frozen Must be thawed before toasting.
Conveyor Toasters, 350-1000 Slices Per Hour Operator’s Manual – Models JT2, JT2H, JT3, JT3H 3
CLEANING
NOTICE: Do not use abrasive materials, scratching cleansers or
scouring pad to clean the exterior of the equipment. These
can damage the finish.
Daily Cleaning
1. Rotate the power knob to the OFF position (O) and unplug the
toaster.
2. Let the toaster cool completely.
3. Slightly dampen a soft cloth with a warm water.
4. Use the dampened cloth to clean the exterior of the toaster, the air
intake under the toaster, the feed ramp, and collection tray.
Clean the Conveyor
1. Plug in the toaster.
2. Rotate the power knob to the ON position (|).
3. Rotate the conveyor speed knob to 10.
4. Press and hold a heat resistant (steel wool, metal wire brush, etc)
abrasive pad or brush against the conveyor. Move the pad or brush
back and forth (left to right) across the conveyor to remove food
debris.
5. Empty and clean the crumb tray.
PREVENTATIVE MAINTENANCE
Contact an authorized service agent for a professional cleaning of the
components.
WARNING
Electrical Shock Hazard
Do not spray water or cleaning products. Liquid could contact
the electrical components and cause a short circuit or an
electrical shock.
CAUTION
Burn Hazard
Allow equipment to cool before moving or cleaning.
TROUBLESHOOTING
Problem Might be Caused By Course of Action
Toaster does not heat and the
conveyor belt does not move.
Toaster is not plugged in. Plug in the toaster.
Power knob setting is incorrect. Rotate the power knob to full power.
The wall breaker may be tripped. Reset the breaker.
The reset may be tripped. Look under the toaster to see if an object is preventing the fan
blades from turning.
1. Rotate the heat control knobs to the OFF position.
2. Rotate the power knob to the OFF (O) position.
3. Unplug the toaster.
4. Wait 30 minutes for the toaster cool.
5. Remove the object.
6. Plug in the toaster.
7. Rotate the power knob to the ON (|) position.
8. Press the reset button.
9. If the problem persists call Vollrath Technical Services.
