Side 1/5

compact

Objective Lens

Ocular Lens

Twist-up Eyecup

Strap

Attachment

Tripod Adapter Socket

Center Focus

Diopter

IPD

The eyecups on a Diamondback® binocular twist up and down so

any viewer can see the full ﬁ eld and enjoy comfortable viewing—

with or without eyeglasses.

When not using eyeglasses or

sunglasses, keep the eyecups fully

extended. For the best viewing

when viewing through eyeglasses,

twist eyecups down.

Adjust the interpupillary distance

The interpupillary distance (IPD) is the distance between the centers

of the left and right eye pupils. Match the IPD of your eyes to that of

the binocular so that you see a single image that is free of shading.

BASIC OPERATION

Adjust the eyecups

Rotate the binocular barrels

inward or outward to line your

eyes up with ocular lenses.

Distance between the centers

of the ocular lenses.

Produkspesifikasjoner

Merke:	Vortex
Kategori:	Kikkert
Modell:	Diamondback 10x28
Vekt:	382.7 g
Bredde:	116.8 mm
Dybde:	111.8 mm
Høyde:	- mm
Vanntett:	Ja
Objektiv diameter:	28 mm
Produktfarge:	Black, Green, Grey
Halsstropp inkludert:	Ja
Bæretaske:	Ja
Forstørring:	10 x
Objektivbelegg:	Fully Multi Coated (FMC)
Prismetype:	Tak
Synsfelt (ved 1000 m avstand):	83 m
Virkelig synsfelt:	5.1 °
Nærmeste fokuseringsavstand:	2 m
Pupillavstand (min):	55 mm
Pupillavstand (max):	74 mm
Øyehvile:	16 mm
Utgangspupill:	2.8 mm
Øye beskytter type:	Twist-up
