Side 1/5

3 2

Objective Lens

Ocular Lens

Twist-up Eyecup

Strap

Attachment

Tripod Adapter Socket

Center Focus

Diopter

IPD

The eyecups on a Diamondback

binocular twist up

and down so any viewer can see the full eld and enjoy

comfortable viewing—with or without eyeglasses.

When not using eyeglasses or

sunglasses, keep the eyecups

fully extended. For the best

viewing when wearing glasses,

twist eyecups down.

Adjust the interpupillary distance

The interpupillary distance (IPD) is the distance between the

center of your left and right pupils. Match the IPD of your eyes

and your binocular by rotating the barrels in or out until you see

a single image free of shading.

Basic OperatiOn

Adjust the eyecups

Rotate the barrels in or out to

match the IPD of your eyes with

that of the binocular.

Distance between the centers

of the ocular lenses.

Produkspesifikasjoner

Merke:	Vortex
Kategori:	Kikkert
Modell:	Diamondback 10x42
Vekt:	691 g
Bredde:	142 mm
Høyde:	150 mm
Objektiv diameter:	42 mm
Forstørring:	10 x
Prismetype:	Tak
Nærmeste fokuseringsavstand:	1.52 m
Øyehvile:	16 mm
Utgangspupill:	4.2 mm
