Side 1/24
AC30S1
GUITAR AMPLIFIER
Owner’s Manual
Manuel d’utilisation
Bedienungsanleitung
Manual de Usuario
取扱説明書
EFGSJ 2
2
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong.
The wide blade or the third prong are provided for your
safety. If the provided plug does not t into your outlet, con-
sult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specied by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specied by the man-
ufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
• WARNING—This apparatus shall be connected to a mains
socket outlet with a protective earthing connection.
• WARNING—The mains plug or appliance coupler is used
as the disconnect device, the disconnect devices shall
remain readily operable.
• Mains powered apparatus shall not be exposed to dripping
or splashing. No objects lled with liquids, such as vases
or drinking glasses, shall be placed on the apparatus.
• Turning off the power switch does not completely isolate
this product from the power line.
• Keep the power plug easily accessible. Do not install this
equipment far from a power outlet and/or power strip.
• Do not install this equipment in a conned space such as
a box for the conveyance or similar unit.
• Excessive sound pressure from earphones and head-
phones can cause hearing loss.
• This apparatus is for moderate climates areas use, not
suitable for use in tropical climates countries.
• The ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.
• No naked ame sources, such as lighted candles, should
be placed on the apparatus.
The lightning ash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
THE FCC REGULATION WARNING (for USA)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If items such as cables are included with this equipment, you must
use those included items.
Unauthorized changes or modication to this system can void the
user’s authority to operate this equipment.
SUPPLIER’S DECLARATION OF CONFORMITY (for USA)
Responsible Party : KORG USA INC.
Address : 316 SOUTH SERVICE ROAD, MELVILLE, NY
Telephone : 1-631-390-6500
Equipment Type : GUITAR AMPLIFIER
Model : AC30S1
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Notice regarding disposal (EU only)
When this “crossed-out wheeled bin” symbol is displayed on
the product, owner’s manual, battery, or battery package,
it signies that when you wish to dispose of this product,
manual, package or battery you must do so in an approved
manner. Do not discard this product, manual, package or
battery along with ordinary household waste. Disposing in
the correct manner will prevent harm to human health and
potential damage to the environment. Since the correct method of
disposal will depend on the applicable laws and regulations in your
locality, please contact your local administrative body for details.
If the battery contains heavy metals in excess of the regulated
amount, a chemical symbol is displayed below the “crossed-out
wheeled bin” symbol on the battery or battery package.
*
All product names and company names are the trademarks or registered trade-
marks of their respective owners.
3
INTRODUCTION
Congratulations on your purchase of the VOX Custom Series AC30S1 Guitar Amplier.
This amp is the culmination of over 60 years of manufacturing expertise and high quality guitar
amplier design. We’ve taken our most iconic amplier, the classic AC30 and re-engineered it to
become the AC30S1.
A streamlined, single channel design with more than enough exibility to satisfy your tonal de-
sires and playing requirements. Whilst retaining the unmistakable AC30 sound!
Your AC30S1 is equipped with a number of modern features and conveniences, including a
master volume, Celestion VX12 speaker and custom VOX reverb to name a few. Please read this
manual carefully so that you can familiarize yourself with them.
FRONT PANEL LAYOUT
1. MAINS Indicator
This will tell you if your amp is on or off!
2. MAINS Power switch
This is the ON/OFF switch for the power to the amplier. Please ensure
the amplier is switched off and unplugged before being moved.
3. STANDBY switch
Puts the amplier into STANDBY Mode. Meaning no output, just nicely
warmed tubes.
4. VOLUME Control
This controls the overall VOLUME of your amplier. Cleaner sounds can
be achieved by lowering the GAIN and raising the VOLUME. Setting the
VOLUME lower and the GAIN higher will give you a fatter, more distorted
tone at a lower volume. As with all the controls of this amplier, please ex-
periment with different congurations to nd the tones that t your guitar
and playing style.
5. REVERB Control
This controls the level of reverb in your sound. Ranging from subtle ambi-
ence to a spacious swell, the new Custom VOX reverb adds great sonic
depth to your tone.
6. TREBLE Control
This controls the high frequencies in your sound—from soft and round
when turned down (counter clockwise) to bright and cutting when cranked
(clockwise) and all points in-between.
7. BASS Control
This controls the low frequencies in your sound—from thin and light when
turned down (counter clockwise) to warm and heavy when turned up full
(clockwise) and all points in-between.
STANDBY
GAIN
TREBLE
BASS
VOLUME
REVERB
ON
OFF
MAINS
HT
ON
INPUT
1234 5678 9
