Mi 33W Wall Charger (Type-A + Type-C) User Manual 1
Manual de usuario de Mi 33W Wall Charger (Type-A + Type-C) 4
Manuale utente Mi 33W Wall Charger (Type-A + Type-C) 7
Manuel d'utilisation de Mi 33W Wall Charger (Type-A + Type-C) 10
Mi 33 W Wandladegerät (Typ-A + Typ-C) Benutzerhandbuch 13
Mi 33 W Muuroplader (Type-A + Type-C) Gebruikershandleiding 16
Manual do utilizador do Carregador de Parede Mi 33 W
(Tipo-A + Tipo-C) 19
Посібник користувача Настінного зарядного пристрою Mi 33 Вт
ип А + Тип С) 22
Mi 33 W Duvar Tipi Şarj Cihazı (Type-A + Type-C)
Kullanım Kılavuzu 25
Ładowarka ścienna Mi 33 W (typ A + typ C) Instrukcja obsługi 28
Руководство пользователя Зарядным устройством Mi 33W Wall
Charger (Type-A + Type-C) 34
Mi ﻦﻣ (C-عﻮﻨﻟا + A-عﻮﻨﻟا) طاو 33 ﻂﺋﺎﺣ ﻦﺣﺎﺷ مﺪﺨﺘﺴﻤﻟا ﻞﻴﻟد 31
1
Read this manual carefully before use, and retain it for future reference.
Thank you for using this product. This product
is compatible with mainstream digital devices
available in the market, and has an output
power of up to 33 W max., dual-port output
and a compact size for easy portability.
Illustrations of product, accessories, and user interface in the user manual are for
reference purposes only. Actual product and functions may vary due to product
enhancements.
AC adaptor is use for IT equipment only.
Product Overview
Specifications
Name: Mi 33W Wall Charger (Type-A + Type-C)
Model: AD332EU
Output Port: Type-A & Type-C
Input: 100–240 V~ 50/60 Hz 1.1 A
Dual-port Output: 5.0 V=4.5 A 22.5 W Max.
Type-C Single Port Output: 5.0 V=3.0 A 15.0 W, 9.0 V=3.0 A 27.0 W, 10.0 V=2.25 A 22.5 W,
11.0 V=3.0 A 33.0 W, 12.0 V=2.5 A 30.0 W, 15.0 V=2.0 A 30.0 W, 20.0 V=1.65 A 33.0 W
Type-A Single Port Output: 5.0 V=3.0 A 15.0 W, 9.0 V=3.0 A 27.0 W, 10.0 V=2.25 A 22.5 W,
12.0 V=2.25 A 27.0 W
Operating Temperature: 0°C to 40°C
Item Dimensions: 48 × 64.7 × 28 mm (excl. prongs)
Average Active Efficiency: 83.4 %
Efficiency at 10% Load: 73.7 %
No-load Power Consumption: 0.05 W
Type-C Type-A
2
Safety Features: Multiple protective functions including short circuit protection,
overcurrent protection, overvoltage protection, overheating protection, and
undervoltage protection. The USB-C interface has an independent high-precision
current-limiting chip built-in to ensure that the charger works within the normal
current range. Its shell is made of V0 grade fireproof and high temperature resistant
material, which is safe and reliable.
Compatibility: Built-in smart identification chip, compatible with mainstream
smartphones and other electronic devices available in the market.
Fast Charging: The dual-port output supports multiple devices; the type-A port
supports 27 W smart fast charging; the type-C port supports up to 33 W smart fast
charging when used individually; and the total output of both ports can reach 5 V/4.5 A
when used simultaneously.
Appearance: Compact & portable.
Applicability: Suitable for use at altitudes up to 5000 meters.
Product Features
Do not disassemble this charger.
Do not expose this charger to heat sources, fire, or environments with ambient
temperatures over 60°C (140°F). Do not leave this charger in direct sunlight.
Do not short circuit this charger.
Do not subject this charger to excessive force.
Children must be supervised by an adult when using this charger.
Warnings
The manufacturer hereby, declares that this equipment is in compliance
with the applicable Directives and European Norms, and amendments.
The full text of the EU declaration of conformity is available at the
following internet address:
hp://www.mi.com/global/service/support/declaration.html
CE
