ELECTRIC GUITAR

OWNER’S MANUAL

CONTENTS

VIBRATO SYSTEM Locking Type (part 2) ........................... 7

BRIDGE/SPRING TENSION ADJUSTMENTS ...................... 8

TRUSS ROD ADJUSTMENT ............................................... 9

PICKUP HEIGHT ADJUSTMENT ........................................ 9

CORRECT USE AND HANDLING OF BATTERIES ............. 10

Safety Precautions ............................................................ 11

CARE AND MAINTENANCE ................................................ 2

TUNING MACHINE TENSION ADJUSTMENT ...................... 3

HEIGHT ADJUSTABLE LOCKING NUT ............................... 3

SETTING THE STRING ACTION ......................................... 4

VIBRATO SYSTEM Vintage Type ........................................ 5

VIBRATO SYSTEM Locking Type (part 1) ........................... 6

01egomen.indd1

01egomen.indd101egomen.indd1 09.3.139:41:40AM

09.3.139:41:40AM

09.3.139:41:40AM09.3.139:41:40AM

CARE AND MAINTENANCE

Congratulations on your purchase of the

YAMAHA electric guitar.

With reasonable care, your YAMAHA elec-

tric guitar will age gracefully and provide

many years of superlative musical service.

* When connecting or disconnecting cables, turn off the am-

plifier and other equipment or reduce the volume.

* After playing, wipe the entire guitar down, including strings,

with a good polishing cloth. This will remove corrosive skin

oils and acids, and protect the plating, finish, and strings.

* Avoid exposing the guitar to direct sunlight and extremes of

heat and humidity.

01egomen.indd2

01egomen.indd201egomen.indd2 09.3.139:41:40AM

09.3.139:41:40AM

09.3.139:41:40AM09.3.139:41:40AM

TUNING MACHINE TENSION ADJUSTMENT

HEIGHT ADJUSTABLE LOCKING NUT

The tuning machines have spring-loaded mechanisms which

automatically take up wear, preventing backlash. However, it is

possible to adjust the amount of pressure required to turn the

machines. Each machine has a tension adjustment screw, as

illustrated.

1) Remove 3 pcs. of hexagonal screws fixing the Lock Pads.

(illustration — A)

2) Loosen 4 pcs. of screws fixing the Nut Base.

(illustration — B)

3) Adjust the height by the Height Adjustment Screw. The Nut

Base gets higher by clockwise rotation, and lower by coun-

terclockwise rotation. (illustration — C)

Clockwise screw rotation tightens the machine. The tuning ma-

chines should be adjusted to the extent that they are firm, but

can turn smoothly. This adjustment is normally unnecessary,

and excessive tightening can lead to premature tuning machine

wear.

NOTE:

As the height has been adjusted in the best con-

dition in the factory, please avoid the adjustment

unless you have suitable experience. We suggest

that you entrust this adjustment to your dealer.

Loosen

Tighten

01egomen.indd3

01egomen.indd301egomen.indd3 09.3.139:41:40AM

09.3.139:41:40AM

09.3.139:41:40AM09.3.139:41:40AM
