Side 1/289
EXO User Manual
ADVANCED WATER QUALITY MONITORING PLATFORM
USER MANUAL
ITEM# 603789REF
REVISION L
2
The information contained in this manual is subject to change without notice.
Effort has been made to make the information in this manual complete, accurate, and current.
The manufacturer shall not be held responsible for errors or omissions in this manual.
Consult YSI.com/EXO for the most up-to-date version of this manual.
Safety Information
Please read this entire manual before unpacking, setting up or operating this equipment. Pay attention to all precautionary
statements. Failure to do so could result in serious injury to the operator or damage to the equipment. Make sure that the
protection provided by this equipment is not impaired. Do not use or install this equipment in any manner other than that
specified in this manual.
Precautionary Symbols
NOTE: Information that requires special emphasis
NOTICE: Indicates a situation which, if not avoided, may cause damage to the instrument
CAUTION: Indicates a potentially hazardous situation that may result in minor or moderate injury
WARNING: Indicates a potentially hazardous situation which could result in death or serious injury
Product Components
Carefully unpack the instrument and accessories and inspect for damage. If any parts or materials are damaged, contact YSI
Customer Service at 800-897-4151 (+1 937 767-7241) or the authorized YSI distributor from whom the instrument was purchased.
Technical Support
Telephone: 800 897 4151 (USA), +1 937 767 7241 (Globally)
Monday through Friday, 8:00 AM to 5:00 ET
Fax: +1 937 767 9353 (orders)
Email: info@ysi.com
YSI.com
A
A
When viewing this document as an Adobe
TM
PDF, hovering your
cursor over certain phrases will bring up the finger-point icon. Clicking
elements of the Table of Contents, website URLs, or references to certain
sections will take you automatically to those locations.
THIS IS AN INTERACTIVE DOCUMENT
It’s your world. Protect it.
It’s your world. Protect it.
It’s your world. Protect it.
EXO University
Watch our on-demand training
videos for all things EXO!
YSI.com/EXO-University
3
TABLE OF CONTENTS
1. EXO Platform Overview
1.1 EXO1 Sonde Overview
1.2 EXO1
S
Sonde Overview
1.3 EXO2 Sonde Overview
1.4 EXO2
S
Sonde Overview
1.5 EXO3 Sonde Overview
1.6 EXO3
S
Sonde Overview
1.7 EXO Field Cables Overview
1.8 EXO Handheld Overview
1.9 EXO GO Overview
2. Operation
2.1
Sonde Install / Replace EXO1 Batteries
2.2
Sonde Install / Replace EXO2 and EXO3 Batteries
2.3
Install / Remove Guard or Cal. Cup
2.4
Install / Remove Sensors
2.5
Sonde States and LED Descriptions
2.6
Connection Methods Overview
2.7
Awaken Sonde, Activate Bluetooth
2.8
Connect Sonde, Bluetooth
2.9
Connect Sonde, SDI-12 - EXO3 Only
2.10
Communication Adapters Overview
2.11
Communication Adapters, USB
2.12
Communication Adapters, DCP
2.13
Communication Adapter, RS-232
2.14
Communication Adapters, SDI-12
2.15
Communication Adapters, Modbus
2.16
Connect Sonde, Flow Cell
2.17
Daisy Chaining, Sonde Expansion
2.18
Sonde Clamping / Mooring, Long-Term Monitoring
3. Kor Software
3.1
Introduction
3.2
Installation
3.3
Instrument Connection Panel
3.4
Home Screen
3.5
File Menu
3.6
Calibration Screen
3.7
Deployment Screen
3.8 Sites Menu
3.9 Live & Recorded Data
3.10 Recorded Data Menu
3.11 Instruments and Sensors
4. Kor Mobile
4.1 Installing Kor
4.2 Setup
4.3 App Settings
4.4 Navigation
4.5 Connection
4.6 Live Data
4.7 Data Management
4.8 Site Management
4.9 Deployment
4.10 Calibration
4.11 Instrument Settings
4.12 Contact YSI
5. Sensors and Calibration
5.1 Sensors Overview
5.2 Calibration Basic Overview
5.3 Calibration Report
5.4 SmartQC Overview
5.5 Conductivity / Temperature Sensor Overview
5.6 Conductivity / Temperature Calibration
5.7 Wiped Conductivity / Temperature Sensor Overview
5.8 Wiped C/T Calibration and Deployment
5.9 Depth and Level Sensor Overview
5.10 Depth and Level Calibration
5.11 Dissolved Oxygen Sensor Overview
5.12 Dissolved Oxygen Calibration
5.13 fDOM Sensor Overview
5.14 fDOM Calibration Standards
5.15 fDOM Calibration
5.16 ISEs: Ammonium, Nitrate, & Chloride Overview
5.17 ISEs: Ammonium, Nitrate, & Chloride Calibration
5.18 NitraLED UV Nitrate Overview
5.19 NitraLED Calibration and Correction
5.20 pH and ORP Sensor Overview
5.21 pH Calibration
5.22 ORP Calibration
5.23 Rhodamine Sensor Overview
5.24 Rhodamine Calibration
5.25 Total Algae Sensor Overview
5.26 Total Algae Calibration
5.27 Turbidity Sensor Overview
5.28 Turbidity Calibration
5.29 Total Suspended Solids Calculation
