Zoom ZUM-2 Bruksanvisning
Les nedenfor 📖 manual på norsk for Zoom ZUM-2 (1 sider) i kategorien Mikrofon. Denne guiden var nyttig for 15 personer og ble vurdert med 4.8 stjerner i gjennomsnitt av 8 brukere
Side 1/1
ZOOM CORPORATION
4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan zoomcorp.com
© 2021 ZOOM CORPORATION Copying or reprinting this manual in part or in whole without permission is prohibited. Product names, registered trademarks and company names in this
document are the property of their respective companies. All trademarks and registered trademarks in this document are for identication purposes only and are not intended to infringe on
the copyrights of their respective owners. You might need this manual in the future. Always keep it in a place where you can access it easily. The contents of this manual and the
specications of the product could be changed without notice.
Features
• Plugs directly into your computer via USB, no driver
required
• Compatible with most recording, streaming and
teleconferencing software
• Broadcast-quality sound
• Super Cardioid Polar Pattern to reject unwanted sounds
• Record sample rates up 24-bit/96 kHz
• Built-in headphone output with volume control for
monitoring computer sound output
• Included foam windscreen reduces breath and popping
sounds
Specications
Type: Back Electret Condenser | Polar Pattern: Supercardioid |
Frequency Response: 20-20,000 Hz | Sensitivity: -35 dBV/Pa | Max.
SPL: 135 dB SPL | Sampling Frequency: 44.1/48/88.2/96 kHz | Bit
depth: 24-bit | Power Requirements: USB bus power DC 5V |
Dimension: Ø54 × 150 mm | Net Weight : 422 g | Output : USB (Type-C)
/ Headphone (3.5 mm phone jack), 110 mW + 110 mW (32 Ω load)
Furnished Accessories
Windscreen
USB Type-A to
USB Type-C cable
TPS-4 Tripod
mic stand
Z2I-4225-01
ZUM-2 ZOOM USB MIC
❶
Power Indicator
Blue light shows mic is receiving USB power when
connected to your computer.
❷
Headphone Volume Knob
Control the headphone volume.
❸
Headphone Output Jack
1/8”(3.5 mm) stereo jack for connecting your
headphones.
❹
USB Port (Type-C)
USB Type-C port for connecting your computer.
Connecting computer
Functions of parts
Pivoting
Stand Mount
Polar Patterns
100005000
Frequency Response
0
RELATIVE RESPONSE IN dB
FREQUENCY IN Hz
200010005002001005020
-10
-20
dB
10
0°
45°
45°
90°90°
135°135°
180°
20000 Hz
Threaded adapter
5/8"-3/8”
Preliminary setup with computer
macOS
Open >> Click >>Click the System Preferences Sound
Input Output ZUM-2 tab and the tab to select as the
device for sound input and output.
Windows
Open the >> Click Start Menu
( )Settings Application
>> Click >> Click on the left panel >> System Sound
Choose ZUM-2 in the drop-down menus for Output and
Input.
1.5m
USB cable
Type-C Type-A
Use a USB cable that supports
data transfer.
❶
❷
❸
❹
Produkspesifikasjoner
| Merke: | Zoom |
| Kategori: | Mikrofon |
| Modell: | ZUM-2 |
