User Manual
AIMB-508
12th/13th Gen Intel
®
Core™ i9/i7/
i5/i3 Processors (LGA1700),
Micro-ATX with DP/HDMI/VGA/
eDP (LVDS), 1 x GbE LAN,
1 x 2.5GbE LAN, 8 x USB 3.2,
2 x PCI slot, 10 x COM
AIMB-508 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2024
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgments
AMI is a trademark of American Megatrends International, LLC.
IBM and PC are trademarks of International Business Machines Corporation.
Intel
®
Core™ i9/i7/i5/i3, Pentium
®
, and Celeron
®
are trademarks of Intel Corporation.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 Years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers will be billed according to the cost of replacement mate-
rials, service time, and freight. Please consult your dealer for more details.
If you believe your product to be defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.
Part No. 2006050802 Edition 3
Printed in China October 2024
iii AIMB-508 User Manual
Declaration of Conformity
FCC Class B
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for assistance.
CPU Compatibility
CPU Family Code Name Cores Number (P+E)** TDP (W) Max. Speed L3 Cache
i9-13900E Raptor Lake 8P+16E 65W 5.20GHz 36MB
i9-13900TE Raptor Lake 8P+16E 35W 5.00GHz 36MB
i7-13700E Raptor Lake 8P+8E 65W 5.10GHz 30MB
i7-13700TE Raptor Lake 8P+8E 35W 4.80GHz 30MB
i5-13500E Raptor Lake 6P+8E 65W 4.60GHz 24MB
i5-13500TE Raptor Lake 6P+8E 35W 4.50GHz 24MB
i3-13100E Raptor Lake 4P+0E 65W 4.40GHz 12MB
i3-13100TE Raptor Lake 4P+0E 35W 4.10GHz 12MB
i9-13900 Raptor Lake 8P+16E 35W 5.60GHz 36MB
i7-13700 Raptor Lake 8P+8E 35W 5.20GHz 30MB
i5-13500 Raptor Lake 6P+8E 65W 4.80GHz 24MB
i5-13400 Raptor Lake 6P+4E 65W 4.80GHz 20MB
i3-13100 Raptor Lake 4P+0E 60W 4.50GHz 12MB
i9-12900E Alder Lake 8P+8E 65W 5.0GHz 30 MB
i9-12900TE Alder Lake 8P+8E 35W 4.8GHz 30 MB
i7-12700E Alder Lake 8P+4E 65W 4.8GHz 25 MB
i7-12700TE Alder Lake 8P+4E 35W 4.7GHz 25 MB
i5-12500E Alder Lake 6P+0E 65W 4.5GHz 18 MB
i5-12500TE Alder Lake 6P+0E 35W 4.3GHz 18 MB
i3-12100E Alder Lake 4P+0E 60W 4.2GHz 12 MB
i3-12100TE Alder Lake 4P+0E 35W 4.0GHz 12 MB
G7400E Alder Lake 2P+0E 46W 3.6GHz 6 MB
G7400TE Alder Lake 2P+0E 35W 3.0GHz 6 MB
G6900E Alder Lake 2P+0E 46W 3.0GHz 4 MB
G6900TE Alder Lake 2P+0E 35W 2.4GHz 4 MB
