Side 1/49

EN-ENGLISH

BT Portable Speaker

ABTS-21H USER GUIDE

Important Safety Instruc ns

1. To assure the ﬁnest performance, please read this manual carefully. Keep it in a safe place for future

reference.

2. Locate this unit away from other electrical appliances, motors, or transformers to avoid humming

sounds.

3. Do not expose this unit to sudden temperature changes from cold to hot. Do not locate this unit in an

environment with high humidity (i.e. a room with a humidiﬁer) to prevent condensa

n inside this unit,

which may cause an electrical shock, ﬁre, damage to this unit, an

d/or personal injury.

4. Avoid installing this unit where foreign objects may fall into this unit and/or this unit may be exposed to

liquid dripping or splashing.

5. Never place objects on top of this unit as they may cause damage to the unit or discolor it.

6. Never place candles, lit objects or containers with liquids such as vases on the unit, as doing so is

extremely hazardous, may cause personal injury and/or major damage to the unit.

7. Do not cover

this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radia n

8. If the temperature inside this unit rises, it may cause ﬁre, damage to this unit, and/or personal injury.

9. Do not operate this unit upside down as it may overheat and cause damage.

10. Do not use force on switches, knobs and/or cords.

128克铜版纸双面单黑印刷 A6 尺寸订成册

EN-ENGLISH

11. When disconnecting the power cable from the wall outlet, grasp the plug; do not pull the cable.

12. Do not clean this unit with chemical solvents as these may damage the finish. Use a clean, dry cloth.

13. Only the voltage specified on this unit may be used. Using this unit with a higher voltage than specified

is dangerous and may cause fire, damage to this unit and/or personal injury. We will not assume any

liability for damage resulting from use of this unit with a voltage other than specified.

14. To prevent damage by lightning, keep the power cable and outdoor antennas disconnected from a wall

outlet or this unit during a lightning storm.

15. CAUTION: NEVER attempt to open this unit to modify, fix or repair this unit! Refer all service, repairs

and maintenance to an authorised service center.

ACCESSORIES

1x Charging cable

1x Audio cable

1x User Manual

TECHNICAL SPECIFICATIONS

• Power Source 5V/1-2A

• Power Consumption 10W (1K0DB)

• RMS Power 6.5W, 4Ω

• Bluetooth version V5.0+BR+EDR+BLE

• BTH channel emission power 2dbm

• Bluetooth frequency 2,402 GHz- 2,480 GHz

• Bluetooth range 10m

• FM frequency 87.5-108 MHz

• Battery type 3.7V-1,500mAh

• Speakers 3 inch*1buc

• Frequency response 120Hz-15kHz

• Product dimensions 278(L) *117(l) *156(H) mm

Produkspesifikasjoner

Merke:	Akai
Kategori:	Vugge/dokkingstasjon
Modell:	ABTS-21H
Produkttype:	Bærbar monohøyttaler
Vekt:	955 g
Bredde:	117 mm
Dybde:	278 mm
Høyde:	156 mm
LED-indikatorer:	Ja
Batterikapasitet:	1500 mAh
Bluetooth:	Ja
Wi-Fi:	Nei
Bluetooth-versjon:	5.0
Tilkoblingsteknologi:	Ledning & Trådløs
Pakkevekt:	1150 g
Antall USB 2.0-porter:	1
Antall høyttalere:	1
Volumkontroll:	Knapper
FM-radio:	Ja
Innebygd mikrofon:	Nei
Anbefalt bruk:	Universell
Impedans:	4 Ω
3,5 mm-kontakt:	Nei
Frekvensområde:	120 - 15000 GHz
Bluetooth-rekkevidde:	10 m
FM-bånd:	87.5 - 108 MHz
Produktdesign:	Cylinder
Batteriteknologi:	Lithium-Ion (Li-Ion)
Batteritype:	Innebygd batteri
Batteriladetid:	4 timer
Støttede lydformater:	MP3, WAV, WMA
Produktfarge:	Sort
Pakkedybde:	295 mm
Pakkehøyde:	179 mm
Pakkebredde:	143 mm
Batteriliv (maks.):	4 timer
Kabler inkludert:	AC, Audio (3.5mm)
Batterispenning:	3.7 V
Pakketype:	Boks
Strømforbruk (vanlig bruk):	45 W
Innebygd kortleser:	Nei
AUX-inngang:	Ja
Kroppsmateriale:	Plast
Av/på-bryter:	Ja
Total Harmonic Distortion (THD):	10
Lyd-utgang kanaler:	1.0 kanaler
RMS-rangert strøm/utgangseffekt:	6.5 W
Belysningsdiode:	Ja
Frekvensrekkevidde:	120 - 15000 Hz
Diskanthøyttalerens diameter:	3 "
True Wireless Stereo-teknologi (TWS):	Ja
Bluetooth-overføringskraft:	2 dBm
