Side 1/71

NO: G11214190

Issue date: June, 2011

DS321

Compact dual-bay HDD enclosure with RAID

Installation and system optimization guide:

The following manual and guides were carefully prepared by the SilverStone engineering team to help

you maximize the potential of your SilverStone product. Please keep this manual for future reference

when upgrading or performing maintenance on your system. A copy of this manual can also be

downloaded from our website at:

http://www.silverstonetek.com

P. 3

P.10

SPECIFICATIONS

ENGLISH

P. 2

P.17

P.24

P.31

P.38

P.45

P.52

P.58

P.64

简体中文

adi

per

formin

g m

aintenance

n y

our

stem

cop

y o

this

manua

r w

ebs

silverstonetek.com

Contents

DATA STORAGE SERIES DS321

Compact dual-bay HDD enclosure with RAID

•

Configurable RAID function (Non-RAID, RAID 0, RAID 1)

•

Supports large volumes in excess of 2TB

•

USB 3.0 SuperSpeed connection

•

Backwards compatible with USB 2.0 Hi-Speed connection

•

Compact and screw-less design for easy HDD installation

•

Built-in low speed (2800RPM) fan for extra cooling

•

Security lock slot

Model No.

Enclosure material

Application

Interface/ports

Data Transfer

System Requirements(PC)

System Requirements(MAC)

Power supply

Product size

Remarks

SST-DS321

aluminum housing with plastic panel

One or two 3.5” SATA-I or SATA II HDD, 20GB – 2TB per HDD

Supports large volumes in excess of 2TB

1 x USB 3.0 SuperSpeed port (compatible with USB 2.0)

USB 3.0 up to 5Gbps

USB 2.0 up to 480Mbps

USB 3.0:Windows XP/Vista/7

USB 2.0:Windows XP/Vista/7

USB 2.0:Mac OS 10.4 or above

External Power Adapter universal auto-switching (UL, cUL, CE, TUV approved)

Input: AC 100-240V, 50-60Hz

Output: DC +12V/3A

182mm x 123mm x 81mm

In order for the computer to access volumes larger than 2TB, both hardware

and operating system need to support large volumes (e.g. Windows Vista,

Windows 7 or Mac OS 10.4 and above)

USB 3.0 is currently not available for Mac OS but the device can still be used

with the older USB 2.0 connection.

All specifications are subject to change without prior notice.

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Vugge/dokkingstasjon
Modell:	DS321
Bredde:	81 mm
Dybde:	182 mm
Høyde:	123 mm
Sertifisering:	UL, cUL, CE, TUV
Materiale:	Aluminium, Plastic
Utgangsstrøm:	12 V
Maksimal dataoverføringshastighet:	5 Gbit/s
Standard grensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1)
Maksimal lagringskapasitet:	3 TB
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Minnekortenhet:	Støttes ikke
DC-inngangskontakt:	Ja
Av/på-bryter:	Ja
Støttede lagringsdriverstørrelser:	3.5 "
Antall lagringsdrivere som støttes:	2
Støttede Mac operativsystemer:	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Antall vifter:	1 vifter
Lagringsmedia:	Harddisk
Grensesnitt for lagringsdriver:	SATA
USB 3.2 Gen 1 (3.1 Gen 1) antall porter:	1
