Side 1/52

WWW.AKAIPRO.COM

 QUICKSTART GUIDE

ENGLISH ( 1 - 10 )

 GUÍA DE INICIO RÁPIDO

ESPAÑOL ( 11 - 20 )

 GUIDE D'UTILISATION RAPIDE

FRANÇAIS ( 21 - 30 )

 GUIDA RAPIDA

ITALIANO ( 31 - 40 )

 KURZANLEITUNG

DEUTSCH ( 41 - 50 )

KEY FEATURES

• 16 pressure and velocity-sensitive MPC pads with four banks each

• MPC technologies include Note Repeat, Swing, 16 Level, Full Level, and Tap Tempo

• 12 software parameters on assignable Q-Link knobs and faders

• Dedicated transport controls transmit MMC, MIDI Clock or MIDI CC messages to DAW and

sequencing applications

• MIDI output over USB and traditional MIDI I/O for controlling software and hardware

• Backlit, easy-to-read screen

• USB bus powered, class compliant: plug and play with one USB cable

• Comes with Editor Librarian software

CONNECTION DIAGRAM

1. Connect a USB cable from your computer to the MPD26. The unit will be powered through the USB

connection. Alternatively, if you do not wish to use a computer in your setup or if you wish to power the

MPD26 externally, please plug in an optional Akai MP6-1 (6V-1A DC) power adapter.

2. If you would like to use an external sound module, connect a 5-pin MIDI cable from the MIDI OUT of

the MPD26 to the MIDI IN of the external device.

3. If you would like to use another MIDI controller in your setup, connect a 5-pin MIDI cable from the MIDI

OUT of the external MIDI device to the MIDI IN of the MPD26.

A NOTE ABOUT USING THE MPD2

WITH SOFTWARE:

1. Make sure that all external devices

are connected to the MPD26 and

that the MPD26 is connected to your

computer, using the included USB

cable, before opening any software

applications on your computer with

which you might want to use the

MPD26. If the unit is not plugged in

before, your software application

might not recognize the MPD26 as

an available device.

2. In your software application, you will

need to set the MPD26 as a default

MIDI input device. This is usually

done in the MIDI section of the

Preferences menu.

COMPUTER

EXTERNAL SOUND

MODULE

EXTERNAL MIDI

DEVICE

POWER (optional,

not included)

Produkspesifikasjoner

Merke:	Akai
Kategori:	mikser
Modell:	MPD26
Antall USB 2.0-porter:	1
Antall kanaler:	- kanaler
Produktfarge:	Sort
MIDI-utgang:	Ja
Digital lydbehandling:	- bit
DJ mixer:	Nei
Videofunksjon:	Nei
