ENGLISH
RM6
PAGING BASE FOR ATMP480Z6XL WITH MICROPHONE GOOSENECK
DECLARATION OF CONFORMITY
The product is in compliance with:
EMC Directive 2014/30/EU, LVD Directive 2014/35/EU, RoHS Directive 2011/65/EU and 2015/863/EU,
WEEE Directive 2012/19/EU.
DESCRIPTION
RM6 is a dedicated paging microphone bases designed to be used with the ATMP480Z6XL amplifier.
OPERATIONS
For all operations refer to the ATMP480Z6XL user’s manual at pages 228.
TECHNICAL SPECIFICATION
Model:
RM6
Connectors
1x MICROPHONE GOOSENECK (supplied)
2x RJ45 LINK (INPUT / OUTPUT)
Controls
ALL ZONES BUTTON
6x ZONE BUTTONS
1x CHIME BUTTON
1x CHIME LEVEL
1x TALK BUTTON
1x MIC LEVEL
Frequency response
60Hz -18KHz (-3dB)
Distortion (THD)
< 0.5% (@ Pnom 1KHz)
S/N Ratio
MIC: ≥70dB
Operating temperature
0 ÷ +45°C
Power Supply +/-15VDC (RJ45)
Power Consumption 3 W
Dimensions (WxHxD) 120 x 66 x 198 mm
Weight 0.5 Kg
PROEL S.p.A.
(World Headquarters - Factory)
Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - Italy
Tel: +39 0861 81241 Fax: +39 0861 887862
www.proel.com
